Wen GN6000

KNOW YOUR GENERATOR
CONTROL PANEL
1. Engine Switch
ON / OFF
2. 12V DC Outlet
3. Multi-Meter
Displays voltage, frequency, total runtime (HHHH), and
session runtime (HH:MM). Press the MODE button to
switch between displays.
4. AC Circuit Breakers (30A)
5. Voltage Selector
120V / 240V
6. L14-30R
(AC 120V/240V, 30A/15A)
7. Grounding Nut
Ground generator to reduce risk of electric shock.
8. Main Breakers
20A
9. TT-30R RV
AC, 120V, 30A
10. NEMA 5-20R
AC, 120V, 20A
11
1 2 3 4 5 6
78910
