SPECIFICATIONS
Rated Wattage 5000 Watts
Surge Wattage 6000 Watts
Rated Voltage
AC: 120V / 240V
DC: 12V
Rated Amperage
AC: 40A / 20A
DC: 8.3A
Phase Single
Frequency 60 Hz
Product Dimensions
Length: 23.2 Inches
Width: 16.9 Inches
Height: 17.2 Inches
Product Net Weight 119 Pounds
GENERATOR
ENGINE
Engine Type 4 stroke, OHV, Single Cylinder with Forced Air Cooling System
Engine Displacement 272cc
Engine Speed 3600 RPM
Fuel Tank Capacity 3.4 Gallons (87 Octane Minimum)
Oil Capacity 33.8 fl. oz.
Half-Load Run Time 7.5 Hours
Lubrication System Splash Lubrication
Spark Plug Type F6TC/ NGK BP6ES
Spark Plug Gap 0.6 - 0.8 mm (0.024 in. - 0.031 in.)
Spark Plug Torque 15 - 20 Nm (11 - 15 ft.-lb.)
Intake Valve Gap 0.1 - 0.15 mm (SAE 0.00394 - 0.00591)
Exhaust Valve Gap 0.15 - 0.20 mm (SAE 0.00591 - 0.00787)
3
