Wen GN6000

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1
GN6000-001
Handle Jacket 2
2 Push Handle 2
3 GN6000-003 Nut, M8 2
4 56500-004 Handle Plug 2
5 GN6000-005 Bolt, M8x40 2
6 GN6000-006 Frame Assembly 1
7 56500-007 Cotter Pin (Wheel) 2
8 GN6000-008
Washer, ɸ17.5xɸ30x3
2
9 56500-008 Wheel 2
10 GN6000-010
Wheel Axle, ɸ16×90
2
11 56500-010 Damping Pad 3
12 56500-011 Clamp 1
13 56500-012 Fuel Switch 1
14 GN6000-013 Fuel Tank 1
15 56500-014 Pressure Relief Valve 1
16 56500-015 Fuel Gauge 1
17 56500-016
Washer, ɸ6.5×2×ɸ25
4
18 56500-017 Bolt, M6×25 4
19 GN6000-018 Fuel Cap 1
20 56500-019 Fuel Gauge Label 1
21 56500-020 Engine 1
22 56500-023 Muffler Gasket 1
23 GN6000-024 Muffler 1
N.P. 56500-024.1 Spark Arrestor 1
24 56500-025 Nut, M8 2
25 56500-026 Bolt, M8×16 2
26 56500-027 Bolt, M5×14 7
27 56500-028 End Cover 1
28 56500-029 Bolt, M5×18 3
29 GN6000-030 Voltage Regulator 1
30 56500-031 Carbon Brush Set 1
31 GN6000-032
Washer A, ɸ6
1
32 GN6000-033
Washer B, ɸ5
1
33 56500-034 Bolt, M6×150 4
GENERATOR
34
NO. PART NO. DESCRIPTION QTY.
34 56500-035 Rear Bracket 1
35 56500-036 Nut, M8 6
36 GN6000-037 Grounding Wire 1
37 GN6000-038
Damping Bracket (Right
Rear)
1
38 56500-1038
Washer B, ɸ6
1
39 GN6000-039
Damping Bracket (Left
Rear)
1
40 56500-040 Bolt, M10-1.25x225 1
41 56500-041
Washer A, ɸ10
1
42 56500-042
Washer B, ɸ10
1
43 GN6000-043 Alternator 1
44 GN6000-044
Damping Bracket (Right
Front)
1
45 GN6000-045
Damping Bracket (Left
Front)
1
46 GN6000-046 Flange Bolt, M8x16 2
47 GN6000-047 Bolt, M6x12 5
48 56500-044 Nut, M6 3
49 56500-045 Washer, M6 4
50 56500-046 Control Panel Assembly 1
51 56500-047 Clamp A 3
52 GN6000-052 Clamp A, Carbon Tank 3
53 56500-049 Carbon Tank 1
54 56500-050 Tube A, Carbon Tank 1
55 56500-051 Tube B, Carbon Tank 1
56 56500-053 Clamp B, Carbon Tank 1
57 GN6000-057 Support Base Assembly 1
58 GN6000-058 Support Base 1
59 56500-059
Damping Pad, Support
Base
2
60 56500-054 Bolt, M6x18 4
61 56500-060 Bolt, M8x16 2
62 56500-055 Bushing 2
63 GN6000-063 Flat Washer, 8mm 4
NOTE: Not all parts may be available for purchase.
