Wen GN6000

37
EXPLODED VIEW & PARTS LIST
ENGINE
NO. PART NO. DESCRIPTION QTY.
69 56500-170
Choke Linkage Lock
Clamp
1
70 56500-171 Throttle Linkage 1
71 56500-172 Idle Spring 1
72 56500-173 Governor Spring 1
73 56500-174
Throttle Adjust Bracket
Assembly
1
74 56500-175
Governor Gear Bracket
Assembly
1
75 56500-176 Fuel Hose, 4×10×126mm 1
76 56500-177 Clamp, Fuel Hose 1
77 56500-178 Clip 1
78 56500-179 Drainage Bolt 2
79 56500-180 Washer, 10x16x1.5mm 2
80 56500-181 Crankcase 1
81 56500-182 Oil Seal, 27×47×7mm 1
82 56500-183 Ignition Module 1
NO. PART NO. DESCRIPTION QTY.
83 56500-184 Wire Board 1
84 56500-185 Flywheel 1
85 56500-186 Cooling Fan 1
86 56500-187 Starter Cup 1
87 56500-188 Nut, M14×1.5 1
88
GN6000-
189
Recoil Starter Assembly 1
89
GN6000-
190
Blower Housing 1
90
GN6000-
191
Recoil Starter 1
91 56500-192 Washer, 6mm 3
92 56500-193 Bolt, M6×10 3
93 56500-1193 Air Filter Bracket 1
94 56500-1194 Clip 2
95
56500-
1195ASM
Valve Cover Assembly 1
NOTE: Not all parts may be available for purchase.
