EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
3-1 GN875i-0301 Crankcase Cover Gasket 1
3-2 GN875i-0302 Bearing, 6202P6 2
3-3 GN625i-0304
Oil Dipstick
Subassembly
1
3-4 GN875i-0304 Pin 2
3-5 GN875i-0305 Crankcase Cover 1
3-6 GN875i-0306 Bolt, M8x40 7
3-7 GN875i-0307 Bearing, 6207P53 1
ASSEMBLY 3 - CRANKCASE COVER
No. Part No. Description Qty.
4-1 GN875i-0401 Balance Shaft Assembly 1
4-2 GN875i-0402
Connecting Rod
Assembly
1
4-3 GN875i-0403 Piston 1
4-4 GN875i-0404 Piston Pin 1
4-5 GN875i-0405 Piston Pin Clip 2
4-6 GN875i-0406 Piston Ring Set 1
4-7 GN875i-0407 Crankshaft Assembly 1
ASSEMBLY 4 - CRANKSHAFT,
CONNECTING ROD
No. Part No. Description Qty.
5-1 GN875i-0501 Camshaft Assembly 1
5-2 GN875i-0502 Seal Guide 1
5-3 GN875i-0503 Valve Spring Retainer 2
5-4 GN875i-0504 Valve Rotator 1
5-5 GN625i-0611 Valve Spring Retainer 2
5-6 GN875i-0506 Exhaust Valve Spring Seat 1
5-7 GN875i-0507 Valve Set 1
5-8 GN875i-0508 Intake Valve Spring Seat 1
5-9 GN875i-0509 Valve Lifter 2
5-10 GN875i-0510 Valve Tappet 2
5-11 GN625i-0606 Lifter Stopper Plate 1
5-12 GN400i-0605 Rocker Shaft Bolt 2
5-13 GN625i-0604 Valve Rocker Arm 2
5-14 GN400i-0603 Valve Adjustment Nut 2
5-15 GN400i-0602 Valve Lock Nut 2
ASSEMBLY 5 - VALVE TRAIN,
CAMSHAFT SUBASSEMBLY
36
