Wen LL2156 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 LL2156-001 Power Cord 1
2 LL2156-002
Socket Head Pan
Screw, M5x8
21
3 LL2156-003 Flat Washer, 5mm 18
4 LL2156-004 Circuit Board Cover 1
5 LL2156-005
Power Cord Strain
Relief
2
6 LL2156-006 Motor 1
N.P. LL2156-006.1
Carbon Brush (set of
2)
1
7 LL2156-007
Socket Head Cap
Screw, M6x20
4
8 LL2156-008 Lock Washer, 6mm 11
9 LL2156-009 Arm Locking Knob 1
10 LL2156-010 Arm Lock Spring 1
11 LL2156-011 Spring Pin 1
12 LL2156-012 Arm Lock 1
13 LL2156-013 Nut, M6 7
14 LL2156-014 Eccentric Wheel 1
15 LL2156-015 Set Screw, M6x10 1
16 LL2156-016 PCB 1
17 LL2156-017 Right Rear Housing 1
18 LL2156-018 Tension Plate 1
19 LL2156-019 Left Rear Housing 1
20 LL2156-020
Socket Head Pan
Screw, M6x50
3
21 LL2156-021
Socket Head Pan
Screw, M6x70
4
22 LL2156-022
Socket Head Pan
Screw, M6x65
1
23 LL2156-023
Socket Head Pan
Screw, M6x80
2
24 LL2156-024 Left Support Plate 1
25 LL2156-025 Rubber Foot 4
26 LL2156-026 Screw, M5x16 4
27 LL2156-027 Flat Washer, 6mm 15
28 LL2156-028
Socket Head Pan
Screw, M6x12
9
29 LL2156-029 Bushing 1
30 LL2156-030 Connecting Rod 1
No. Part No. Description Qty.
31 LL2156-031 Bearing, 628-2Z 2
32 LL2156-032
Connecting Rod Cover
Plate
1
33 LL2156-033 Lock Washer, 8mm 2
34 LL2156-034 Nut, M8 1
35 LL2156-035 Crankshaft Bolt 1
36 LL2156-036 Rocker Arm Shaft 1
37 LL2156-037 Bearing, HK0810 4
38 LL2156-038 Bearing, HK1412 2
39 LL2156-039 Drive Rocker Arm 1
40 LL2156-040 Screw, M4x20 14
41 LL2156-041 Drive Linkage 4
42 LL2156-042 Bearing Sleeve 4
43 LL2156-043 Nut, M4 18
44 LL2156-044
Self-tapping Screw,
ST4.2×10
4
45 LL2156-045 Switch Plate 1
46 LL2156-046 Switch 1
47 LL2156-047 Left Switch Housing 1
48 LL2156-048 Screw, M4x50 2
49 LL2156-049 Flat Washer, 4mm 3
50 LL2156-050 Bearing Cushion 4
51 LL2156-051 Screw, M4x40 1
52 LL2156-052 Speed Knob 1
53 LL2156-053 Screw, M5x8 1
54 LL2156-054 Rubber Bushing 1
55
LL2156-055 Potentiometer 1
56
57 LL2156-057 Arm 1
58 LL2156-058 Lock Washer, 5mm 4
59 LL2156-059 Tension Block 1
60 LL2156-060 Arm Cover 1
61 LL2156-061 Tension Rod 1
62 LL2156-062 Nut, M6 3
63 LL2156-063 Right Support Plate 1
64 LL2156-064
Socket Head Cap
Screw, M10x40
1
65 LL2156-065 Wavy Washer, 10mm 1
66 LL2156-066 Tension Knob 1
22
