EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 3455-001 Bed Way 1
2 3455-002 3 Jaws Chuck 1
3 3455-003 Spindle 1
4 3455-004 Set Screw M6x25 5
6 3455-005 Nut M6 10
7 3455-006 Key M5x40 1
8 3455-007 Key M4x8 2
9 3455-008 Screw M5x12 6
10 3455-009 Spindle Bearing Cover 2
11 3455-010 Ball Bearing 6206ZZ 2
12 3455-011 Spacer 2
13 3455-012 Headstock Casting 1
14 3455-013
High/Low Transmission
Gear 21/29T
1
15 3455-014 Spacer 1
16 3455-015 Spur Gear 45T 1
17 3455-016 Nut M27-1.5 2
18 3455-017 Set Screw M5x8 1
19 3455-018 Steel Ball 2
20 3455-019 Compression Spring 3
21 3455-020 Set Screw M6x6 1
22 3455-021 Retaining Ring 12mm 2
23 3455-022 Ball Bearing 6001 2
24 3455-023 Transmission Gear 12T/20T 1
25 3455-024 Key M4x45 1
26 3455-025 H/L Gear Shaft 1
27 3455-026 Pulley 1
28 3455-027 Retaining Ring 10mm 1
29 3455-028 Timing Belt 136 (1.5x70) 1
30 3455-029 High/Low Shifting Fork 1
31 3455-030 High/Low Shifting Arm 1
32 3455-031 High/Low Shifting Knob 1
33 3455-032 High/Low Shifting Lever 1
34 3455-033 High/Low Shifting Grip 1
35 3455-034 Handle 1
36 3455-035 Handle Mount 1
37 3455-036 Compressive Spring 1
38 3455-037 Indicator 1
39 3455-038 Pinion 25T 1
40 3455-039 Support Screw 2
41 3455-040 Pinion 20T 1
NO. PART NO. DESCRIPTION QTY.
42 3455-041 Headstock Cover 1
43 3455-042 Screw M6x20 5
45 3455-043 Gear 45T 1
46 3455-044 Shaft 1
47 3455-045 Key 4x8 1
48 3455-046 Mount 1
49 3455-047 Screw M5x18 2
50 3455-048 Pinion 20T 2
51 3455-049 Washer 6mm 2
52 3455-050 Screw M6x8 4
53 3455-051 Transmission Cover 1
54 3455-052 Screw M5x45 2
55 3455-053 TPI Cutting Chart 1
56 3455-054 Screw M5x8 1
57 3455-055 Washer 5mm 1
58 3455-056 Bushing With Key 1
59 3455-057 Gear 80T 2
60 3455-058 Shaft 1
61 3455-059 Support Plate 1
62 3455-060 Washer 8mm 2
63 3455-061 Nut M8 4
64 3455-062 Shaft 1
67 3455-063 Screw M5x16 2
69 3455-064 Screw M4x10 3
70 3455-065 Apron 1
71 3455-066 Gib Strip 1
72 3455-067 Washer 5mm 3
73 3455-068 Screw M4x8 2
74 3455-069 Shaft 2
75 3455-070 Half Nut Base 2
76 3455-071 Angle Block 1
77 3455-072 Screw M4x10 2
78 3455-073 Groove Cam 1
79 3455-074 Handle 1
80 3455-075 Shaft 1
81 3455-076 Feeding Gear (A) 11T/54T 1
82 3455-077 Feeding Gear (B) 24T 1
83 3455-078 Screw M6x10 1
84 3455-079 Handwheel 2
85 3455-080
Knob & Screw, M8x55 +
Nut M8
2
MODEL ML712
25
