Wen ML712 User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
184 3455-166 Screw M5x10 1
185 3455-167 Spring Washer, 5mm 1
187 3455-168 Key 3x16 1
188 3455-169 Small Spacer 1
190 3455-170 Spring 2
192 3455-171 Washer 6mm 4
193 3455-172 Screw M8x55 2
194 3455-173 Screw M4x38 1
195 3455-174 Nut M4 1
196 3455-175 Tailstock Base Plate 1
197 3455-176 Screw M5x16 3
198 3455-177 Sleeve 1
199 3455-178 Screw M5x25 1
201 3455-179 Chuck Guard 1
202 3455-180 Shaft 1
205 3455-181 Cap Nut M6 1
206 3455-182 Hex Nut M6 2
207 3455-183 Compression Spring 1
208 3455-184 Washer 6mm 2
209 3455-185 Screw M3x4 4
210 3455-186 Switch Cover 1
212 3455-187 Block 1
232 3455-188 Screw, M4x6 2
NO. PART NO. DESCRIPTION QTY.
251 3455-194 Cylinder Pin, 3x8mm 1
253 3455-195
Self-tapping Screw,
ST2.9x4.5
3
254 3455-196 Cover 1
256 3455-198 Dust Cover 1
257 3455-199 Lead Screw Cover 1
258 3455-200 Washer 4mm 3
266 3455-201 Washer 6mm 3
268 3455-202 Hex Nut M10 1
270 3455-203 Support Pin 1
272 3455-204 Protective Cover 1
303 3455-205 Washer 10mm 1
318 3455-206 Screw M5x20 1
319 3455-207 Washer 5mm 1
320 3455-208 Screw M6x10 4
321 3455-209 Screw M6x16 4
322 3455-210 Key, 3x6mm 1
323 3455-211 Screw M8x25 3
324 3455-212 Screw M4x8 2
325 3455-213 Flange 1
326 3455-214
Self-tapping Screw,
ST2.9x9.5
2
327 3455-215 Screw M6x8 1
NOTE: Parts that wear down over the course of normal use (like saw blades, carbon brushes, etc.)
are not covered by the two-year warranty.
NOTE: Not all parts may be available for purchase.
27

Wen ML712 Specifications

General

Brand	Wen
Model	ML712
Category	Lathe
Language	English
