Wen ML712 User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
86A 3455-081 Three-Ball Handle (Large) 1
86B 3455-082 Three-Ball Handle (Small) 1
87 ML712-087 Dial (Imperial) 2
88 ML712-088 Bracket (Imperial) 1
89 ML712-089 Feed Screw (Imperial) 1
90 3455-086 Nut M5 5
91 3455-087 Screw M6x12 6
92 3455-088 Slide Plate 2
93 3455-089 Saddle 1
94 3455-090 Gib Strip 1
95 ML712-095 Feed Nut (Imperial) 1
96 3455-092 Swivel Disk 1
97 3455-093 Screw M8x20 2
98 3455-094 Nut M4 8
99 3455-095 Screw M4x16 3
100 3455-096 Cross Slide 1
101 3455-097 Screw M5x10 5
102 3455-098 Screw M4x8 2
105 ML712-105 Compound Rest (Lower) 1
106 3455-100 Screw M4x14 3
107 3455-101 Gib Strip 1
108 3455-102 Compound Rest (Upper) 1
109 3455-103 Positioning Pin 1
110 3455-104 Screw M6x25 9
111 3455-105 Clamping Lever 1
112 3455-106 Tool Rest 1
113 3455-107 Stud M10x65 1
114 ML712-114 Cross Feed Screw (Imperial) 1
115 ML712-115 Bracket 1
116 3455-110 Screw M4x12 4
119 3455-111 Nut M18 1
120 3455-112 Main Label 1
122 3455-113 Information Label 1
123 3455-114 Electronics Cover 1
124 3455-115 Power Cord 1
125 3455-116 Rubber Foot 4
126 ML716-126 Chip Tray 1
127 3455-118 Left Leadscrew Bracket 1
128 3455-119 Key 3x16 2
129 ML716-129 Leadscrew (Imperial) 1
131 3455-121 Right Leadscrew Bracket 1
133 3455-122 Screw M3x10 3
134 ML716-134 Rack 1
NO. PART NO. DESCRIPTION QTY.
135 3455-124 Clamp Plate 1
136 3455-125 Washer M10 1
137 3455-126 Screw M6x14 1
138 3455-127 Tailstock Casting 1
139 3455-128 Tailstock Screw 1
140 ML712-140 Bracket 1
141 3455-130 Screw M4x10 4
142 3455-131 Tailstock Quill 1
143 3455-132 Center 1
144 3455-133 Stud M8x40 1
145 3455-134 Clamp 1
146 3455-135 Handle 1
148 3455-136 Pulley 1
150 3455-137 Motor 1
N.P. 3455-137.1 Carbon Brushes, Set of 2 1
151 3455-138 Motor Cover 1
152 3455-139 Power Cord Strain Relief 1
153 ML716-153 Rear Chip Guard 1
154 ML712-154 Feed Direction Label 1
155 3455-141 H/L Label 1
156 3455-143 Warning Label 1
N.P. 3455-144 Gear 30T 1
N.P. 3455-145 Gear 35T 1
N.P. 3455-146 Gear 40T 2
N.P. 3455-043 Gear 45T 1
N.P. 3455-148 Gear 50T 1
N.P. 3455-149 Gear 55T 1
N.P. 3455-150 Gear 57T 1
N.P. 3455-151 Gear 60T 1
N.P. 3455-152 Gear 65T 1
N.P. 3455-153 External Jaw Set 1
N.P. ML712-119 Chuck Key 1
171 3455-155 Clamping Bracket 1
172 3455-156 Retaining Ring Ø8mm 1
173 3455-157 Screw M5x8 4
174 3455-158 Guard 1
175 3455-159 Screw M5x8 7
177 3455-160 Screw M6x20 2
178 3455-161 Emergency Stop Switch 1
179 3455-162 Fuse Box 1
180 3455-163 Variable Speed Control Knob 1
181 3455-164 Toggle Switch 1
182 3455-165 PCB, 120V 1
30
