11. See the lower drawing. Position the Uprights
(53, 54) so that the treadmill Frame (51) is cen-
tered between the Uprights.
Firmly tighten the two Colored Patch Frame
Bolts (1) and the four Upright Bolts (2) (only one
side is shown). Be careful not to overtighten
the Colored Patch Frame Bolts.
Raise the Uprights (53, 54) to the vertical posi-
tion.
11
2
51
1
Top View
10. Attach the ground wire on the Wire Harness (39)
to the indicated hole in the Base (52) with a
Ground Screw (84).
52
39
Ground Wire
10
84
Hole
10
9. Attach the Console (91) to the Right Upright (54)
a
nd the Left Upright (53) with six Handrail Bolts
(8) and six Handrail Star Washers (5). Make sure
that no wires are pinched. Start all six
Handrail Bolts before tightening any of them.
With the help of a second person, carefully lower
the Uprights (53, 54) to the floor. See the drawing
in step 11.
9
8
8
8
5
5
5
8
5
9
1
54
53
To Next Page
