WD ELEMENTS PLAY MULTIMEDIA DRIVE
USER MANUAL
APPENDIX – 58
Appendix
Product Specifications
Environmental Specifications
Note: Specifications are subject to change without notice. Weight info varies based on hard drive
capacity.
Model Name WD Elements Play Multimedia Drive
Description USB 2.0 External HDD with Audio/Video Playback Functionality
R/N (Model Number) B9J
Ports (Rear) Power, mini-USB, HDMI, L/R Audio, Composite Video,
Optical Audio (S/PDIF)
Port (Side) USB 2.0 (Type A)
Button (Rear) Reset (Factory Default/Switches between NTSC/PAL)
LED (Front) Power/Status
Certifications Dolby Digital Plus, Dolby Digital TrueHD, DTS 2.0, USB 2.0, HDMI
OS Supports Win XP SP2 or higher, Win Vista, Win 7, Mac OS X
System Storage 1 TB, 2 TB, or 3 TB
Unit Dimension 225 mm x 149 mm x 41 mm (W x D x H)
8.86 in. x 5.87 in. x 1.61 in. (W x D x H)
Unit Weight 1.05 kg (2.31 lbs.)
Packaging Dimension 311 mm x 89 mm x 200 mm (W x D x H)
12.3 in. x 3.5 in. x 7.9 in. (W x D x H)
Packaging Weight 1.68 kg (3.71 lbs.)
Power Adapter Input: 100-240 VAC, 50/60Hz, 0.5A Max
Output: 12VDC/1.5A (Max)
Power Consumption 18 Watts (Max)
Regulatory Compliance FCC Class B, UL/cUL, CE, C-Tick, VCCI, RoHS, KCC, BSMI, CCC,
GOST
Operating Temp. 41°F to 95°F (5°C to 35°C)
Storage Temp. -40°F to 140°F (-40°C to 65°C)
Operating Humidity 10 to 90% Relative Humidity
Storage Humidity 10 to 95% Noncondensing
11
