Lit. No. 49513, Rev. 00 77 August 15, 2011
2. Pull and hold lock pin out; then rotate handle
DOWN and release lock pin. It must lock into
LOWER hole.
3. Push down top of shoe; shoe will be on the
ground. Repeat Steps 2 and 3 on other side
of snowplow (not required for HTS™ blades).
Back vehicle away.
OFF
Receiver Pin
Stand Hook
Handle
(Pull)
Lock Pin
OFF
Shoe
Handle
REMOVING SNOWPLOW FROM VEHICLE & STORAGE
