3.6.2 Chassis
1. Power Supply 1
2. Power Supply 2
Power Supply = Power Supply OK
= Power Supply Error (Blinking)
3.6.3 Front View 6 slot Standalone/Rear View chassis (Power Supply)
Power Supply = Power Supply OK
= Power Supply Error (Blinking)
Figure 6 - Chassis front
Figure 7 - PSU Indicator LEDs
2
1
