4
Instruction of 2.4Ghz receiver
Model:WFR07S
Type: 7channel 2.4Ghz receiver,4096 resulotion(in the PCMS 4096 resolution)
(Adaptation WFLY 2.4Ghz series),ORGANIC 2.4G
Voltage :4.8V-6V
Current:30mA
Weight:9.6g
Size: 40.42mm x27.27mm x11.88mm
Frequency: 2.400GHz-2.483GHz
1．AIL：Aileron
2．ELE：Elevator
3．THR：Throttle
4．RUD：Rudder
5．GRY： Landing Gear/Gyro
6．PIT： Pitch
7．Auxiliary channel
(Channel 1)----------
(Channel 2)----------
(Channel 3----------
(Channel 4)----------
(Channel 5)----------
(Channel 6)----------
(Channel 7)----------
WFLY PCMS receiver cam compatible with PCMS 4096, PCMS 1024 and PPM modulation
(Adaptive), and have fail safe function.ORGANIC 2.4G
(Note: Any channel can be used as power input)
INSTRUCTION MANUAL
WFT07 REMOTE CONTROL DEVICE
