Plumbing of the Waste Pipe
Plumbing of the Waste Pipe
The outlet of the pump can be connected into the waste
pipe, e.g. existing bath waste. Black rubber fittings are
provided for this.
• In confined bathrooms the pump discharge may go into
the sink waste pipe using suitable adaptors. See Fig 1.5
for 32mm (1
1
/4
") McAlpine examples and the McAlpine
catalogue for other variants.
Use with a Macerator Pump
• Discharge from the Whale
®
pump must go into the top
of the macerator box. Do not use the bottom entries.
See Fig 1.6
• It is preferable to have two separate discharge lines to
waste as any failure of the macerator will not be
detected by the Whale pump.
Fig 1.6
Fig 1.5
22mm
V33T
32mm
(1
1
/4
")
A10V
32mm
(1
1
/4
")
Macerator Pump
7
181.604 (IMATCH).qxp_Layout 1 14/10/2019 11:24 Page 7
