User manual
PRODUCT DESCRIPTION
DETERGENT DISPENSER
TECHNICAL DATA FOR WATER CONNECTION
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter - behind plinth
7. Plinth (removable)
8. Adjustable feet (4)
Water connection
Water supply Cold
Water tap 3/4” threaded hose connector
Minimum water supply pressure 100 kPa (1 bar)
Maximum water supply pressure 1000 kPa (10 bar)
1. Main wash compartment
• Detergentforthemainwash
• Stainremover
•Watersoftener
•Foraliquiddetergentitisrecommendedtouseremovable
plastic partition A (supplied) for a proper dosage. If
powder detergent is used, place the partition into slot B.
2. Prewash compartment
• Detergentfortheprewash
3. Softener compartment
• Fabricsoftener
• Liquidstarch
Pour softener or starch solution only up to the
“MAX” mark.
4. Release button
(press to remove the detergent dispenser for cleaning)
