SERVICE MANUAL
Page | 17
S.NO Part No Description Qty
1 w10678783 TUB SUPPORT ASSY 24",G62 1
2
W10678379 SELF TAPPING SCREW ST 6.3x36-F-ASSY,G62
8
3
w10564588
BRAKE BAND & ARM ASM,G62
1
4
S01132010 SCREW - ST 3.5 X 14.0 - F
5
W10499921 CAPACITOR BRACKET,G62
1
6
W10488531 15 uF Capacitor (P0) with 130uH
1
7
W10508762 DRAIN MOTOR ASSEMBLY
1
8 w10678780 MOTOR PLATE ASSY. 24",G62 1
9
S01132015 SCREW-ST4.2X13-C, PHILIPS, STEEL
3
10
P01011140
CAM
-
RING SPLUTCH
1
11
P01011107
SLIDER SPLUTCH
1
12
P01011152 CAM-SPLUTCH
1
13
W10499978 TRANSMISSION PULLEY ASSY-60Hz,G62
1
14 S01159001 NUT NYLOC 1
15
W10006384 BELT
1
16
S01159001
NUT NYLOC
2
17
W10482302 DRIVE SYSTEM,G62
1
18
S01132035
SCREW
-
ST3.5X10
-
F,SPAN;STEEL
2
19
W10678915
SLOT SENSOR ASSY
1
20
W10673869 COACH BOLT-SQ HEIGHT 6.5 - M8 X20
2
21
P01011139 SPRING - SPLUTCH (CONICAL
1
22
S01128001 HEXAGONAL SCREW (M8 X 16)
4
23
W10491566 Sapphire G62 - 1/3 HP motor
1
DRIVE ASSEMBLY
