Whirlpool LSA 1300 - Sequence Chart

SERVICE MANUAL
Page | 30
SAPPHIRE
-
G62, PHILIPPINES
-
AGITATOR MODEL.
TIMING CHART
Program
Water level
Load sensing
& Fill duration
(In minutes)
Wash duration
(including inbuilt
soak) -In minutes
Rinse duration
(In minutes)
Spin duration
(In minutes)
Total cycle time
(In minutes)
Total cycle time
With Super Soak
(In minutes)
Daily wash
Low Water Level
- 15.5 8.5 6 30 40
Medium Water
level - 21.5 9.5 6 37 49
High Water level
- 28.5 10.5 6 45 60
Quick Wash
Low Water Level
NA 6 5 4.5 15.5 SS not applicable
Medium Water
level NA 6 5 4.5 15.5 SS not applicable
High Water level
NA 6 5 4.5 15.5 SS not applicable
Delicates
Medium Water
level NA 17 8.5 3 28.5 38.5
High Water level
NA 21 9 3 33 46
Easy Iron
Medium Water
level - 21 7.5 5 33.5 44.5
High Water level
- 23.5 8.5 5 37 50
Wool
Medium Water
level NA 33.5 6.5 3 43 SS not applicable
High Water level
NA 35 7 3 45 SS not applicable
Bedlinen
Low Water Level
- 24.5 14 6 44.5 59.5
Medium Water
level - 32 16 6 54 72
High Water level
- 40 16 6 62 83
Whites
Low Water Level
- 39 19 10 70 SS not applicable
Medium Water
level - 57.5 19 10 88.5 SS not applicable
High Water level
- 58.5 19 10 89.5 SS not applicable
Colors
Low Water Level
- 14.5 5.5 5 25 35
Medium Water
level - 20 6 5 31 44
High Water level
- 24.5 7 5 36.5 51.5
Delicates Low
Low
NA 14.5 8 3 25.5 33.5
Easy Iron Low
Low
- 20 6.5 5 24.5 33.5
Stain low Low
- 24.5 7 4.5 123.5 NA
Rinse & Spin
Low Water Level
NA 6.5 6 12.5 SS not applicable
Medium Water
level NA 7 6 13 SS not applicable
High Water level NA 7 6 13 SS not applicable
Spin –
15 15 SS not applicable
Note: a) The total cycle time depends on the water pressure and fill time, the table is based on the normal water pressure (fill time not included)
b) Every extra rinse will add approximately 17 minutes.
c) Modifying the program with extra features will increase cycle time accordingly.
SEQUENCE CHART
