SERVICE MANUAL
Page | 24
S.no
COMPONENT NAME
PART NUMBER
COMPONENT SPECIFICATION
QTY
1
INLET
VALVE
Single In Single
Out
W10530891
a) Nominal voltage : 220/230V AC
b) Nominal frequency : 50/60 Hz
c) Nominal current : 0.02A
d) Nominal power : 7w
1
2
PRESSURE SENSOR
W10633409
a)
Nominal Voltage : 5±0.5 V DC
b) Output Freq : 25.80 - 21 KHz
1
3 LID SWITCH W10588010
a) Switch rating: single pole normally closed,
b) Application Current & Voltage -
-> 0.02mA-5V(DC)
-> 0.38mA - 12V(DC)
1
4
SLOT SENSOR
W10681214
a)
Conducting voltage : 0.8v (max)
b) Blocked voltage : 4.6v (min)
1
5
CAPACITOR
W10705503
a)
Capacitance, voltage: 15μf +5%, / 440 v
b) Inductance : 130 μH with ±7%,
c) Frequency: 50 / 60 Hz
1
6
TORQUE MOTOR
W10508762
a)
Nominal
voltage : 230 V AC
b) Nominal Freq : 50/60 ± 2 Hz
c) Nominal current : 20 ± 3mA
d) Nominal power : 3.5 ± 0.5 w
1
7
MOTOR
W10705502
a)
Nominal Voltage: 220
-
240V AC Single
Phase
b) Frequency : 50/60 Hz ± 2Hz
c) Rated Output Power: 250W
d) Capacitor: 15μf +5%,440V AC
1
8
USER INTERFACE
W10629295
a) 5V DC, 30mA, 12V DC, 12mA
1
9
CCU ASSY - G62 - PHILLIPINNES
W10603745
a)
Nominal Voltage: 220V AC @ 60 Hz.
b) Operating Voltage range : 170V AC to
270V AC
c) Operating frequency : 60 Hz ± 3 Hz
d) Standby Power at nominal voltage : <
0.5W
e) Standby Power Consumption at 270 V AC :
< 1W
1
CONTROL COMPONENTS
AND SPECIFICATION
