Whirlpool LSA 1300 - RID#1 Additional Functions and Error Diagnosis

RID#1 .5 EXTRA RINSE
1)
Extra Rinse selection will be
laundry requires
2) 2X/3X
selection will result in 2
RID#1 .6 SUPERSOAK
1) Super soak option
in the Wash loads
found to be higher
RID#1 .7 DELAY END
1)
Delay End key is used to set the “Delay End” time for the selected wash program
RID#2
ERROR DISPLAY & ITS DIAGNOSIS
RID#2
.1 CHECK WATER ERROR
1)
If desired water level did not attain within 10 mins during fill then Check Water
Error will be popped by means of turning ON the Check water LED.
2)
Inlet valve will move to OFF state after 5 mins from Check water error detection &
waits for start key pres
3) Need to check:
a)
Ensure the Water supply at the inlet.
b)
Check for the blockage at fill hose and at the Inlet valve filter.
c)
Ensure that Inlet valve is turning ON during fill process and if not check for
inlet valve operation
d)
Check for pressure sensor frequency response & kink or puncture at the
pressure hose.
e)
Ensure that drain hose free end should be left in atmosphere not in any
other medium.
f)
Ensure that the Water head is >10ft from
RID#2.2 DRAIN ERROR
1)
If the water in the
“dE” error will be popped with water level group LEDs blinking
2) Need to check:
a)
Ensure that drain
ground level
CONTROL COMPONENTS
AND SPECIFICATION
Extra Rinse selection will be
improving the Rinseability performance whenever the
selection will result in 2
/ 3 Rinse Phases of a selected
cycle
selection improves the Wash performance whenever the dirt level
found to be higher
.
Delay End key is used to set the “Delay End” time for the selected wash program
ERROR DISPLAY & ITS DIAGNOSIS
.1 CHECK WATER ERROR
If desired water level did not attain within 10 mins during fill then Check Water
Error will be popped by means of turning ON the Check water LED.
Inlet valve will move to OFF state after 5 mins from Check water error detection &
waits for start key pres
s after checking the water inlet.
Ensure the Water supply at the inlet.
Check for the blockage at fill hose and at the Inlet valve filter.
Ensure that Inlet valve is turning ON during fill process and if not check for
inlet valve operation
& its connections from PCB to Inlet valve.
Check for pressure sensor frequency response & kink or puncture at the
pressure hose.
Ensure that drain hose free end should be left in atmosphere not in any
other medium.
Ensure that the Water head is >10ft from
the Machine Inlet.
If the water in the
system fails to drain within 4
mins from the start of drain process
“dE” error will be popped with water level group LEDs blinking
Ensure that drain
hose should not be elev
ated for more than 20cms from the
ground level
AND SPECIFICATION
SERVICE MANUAL
Page | 26
