Whirlpool WHESFC - Page 23

23
Conditioner Parts List
Key
No.
Part No. Description
17 7332131 Salt Lid (order decal below)
¢
7336622 Instruction Decal
18 7305257 Rim
19 7335901 Cover, Brinewell
20 7137824
Brinewell Assembly
(including salt level decal)
– 7331258
Overflow Hose Adaptor Kit
(includes Key Nos. 21-23)
21
á
Grommet
22
á
Adaptor Elbow
23
á
Hose Clamp
– 7331664
Brinewell Mounting Hardware Kit
(includes Key Nos. 24 & 25)
24
á
Wing Nut, 1/4-20
25
á
Screw, 1/4-20 x 1-1/2”
26 7305249 Repl. Brine Tank
27 7214383
Bypass Valve Assembly, 1”,
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
28 7139999 Drain Hose, 20 ft.
¢
7346075 Owner’s Manual
¢ Not illustrated.
Questions? Call Toll Free 1-866-986-3223
Monday- Friday, 8 AM - 7 PM EST
or visit www.whirlpoolwatersofteners.com
When you call, please be prepared to provide the model and serial number,
found on the rating decal, typically located on the rim below the salt lid hinges.
To order repair parts call toll free 1-866-986-3223, Monday - Friday, 8 am - 7 pm EST.
Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
Key
No.
Part No. Description
– 7112963
Distributor O-Ring Kit
(includes Key Nos. 1-3)
1
á
O-Ring, 2-7/8” x 3-1/4”
2
á
O-Ring, 13/16” x 1-1/16”
3
á
O-Ring, 2-3/4” x 3”
4 7077870 Top Distributor
5 7105047 Repl. Bottom Distributor
6 7265025 Filter Screen
– 7331177
Tank Neck Clamp Kit
(includes 2 ea. of Key Nos. 7 & 8)
7
á
Clamp Section (2 req.)
8
á
Retainer Clip (2 req.)
9 7247996 Repl. Resin Tank, 10” x 40”
10
0502272 Resin, 1 cu. ft.
7301619 Activated Carbon
11 7124415 Gravel
12 7310202 Repl. Brine Valve Assembly
13 7327568 Float, Stem & Guide Assembly
14 7337482 Power Supply, 28V DC
15 7335163
Repl. Electronic Control Board
(PWA)
16 7346588
Top Cover & Faceplate Assembly,
(order decal below)
¢
7346067 Faceplate Decal
