Fence Configurations for Various Material Sizes
============================================================================
Maximum Material
Widths
Using Various Fence Inserts
Std. +
Material
Std Std +
Std + Std + Std + 2
SMX-40A-1
Thickness Only
SMX-42A
SMX-40A-1
SMX-40A-2 SMX-40A-1 SMX-40A-2
1"
2"
3"
4"
5"
6"
18 17 16
15
14
13
16 15
14
13
12
14
13
12
11
12
11
10
10
9
8
Note: Various fence
combinations
will satisfy more than one cut width requirement.
For example, the set-up using the standard fence and one
SMX-40A-2
will cut 4 x 12, 3 x 13, .
2 x 14 and 1 x 15.
SMX-42A -- 1 inch wide
fence
insert can only be used
in
combination with the standard
fence (SMX-38A). Two 1/4 -
20
x 1" long socket head cap screws are required for attachment.
SMX-40A-1- -- 2 inch wide
fence
insert can be used alone, in combination with thestandard
fence or combined with the standard
fence
and another 2 inch or 3 inch insert. Three 3/8 - 16
x 1" long hex head bolts and special thick washers are required to
mount
each insert.
SMX-40A-2
--
3 inch wide
fence
insert can be used alone, in combination with the standard
fence or combined with the standard
fence
and one 2 inch insert.
Three
3/8 - 16 x 1" long hex
head bolts and special thick
washers
are required for mounting.
