Whynter ARC-14S User Manual

11 | P a g e
AIR FILTERS INSTALLATION
Your Whynter portable air conditioner is equipped with a washable Pre-Filter and an Activated
Carbon Filter.
The washable Pre-Filter removes large particles such as dust, pet hair and dander.
The Activated Carbon filter is designed to remove smoke and other odor. It is recommended
you replace the Activated Carbon filter every 2-3 months or as needed. Follow the steps below
to install the filters.
WARNING: NEVER OPERATE THE AIR CONDITIONER WITHOUT THE PRE-FILTER
1. Pull up the pre-filter frame
2. Remove the Pre-Filter from the filter frame.
3. Place the Activated Carbon filter on the Pre-Filter.
4. Reattach the filter frame.
5. Insert the assembled filter frame into the unit.

Whynter ARC-14S Specifications

General

Cooling Capacity	14, 000 BTU
Coverage Area	Up to 500 sq. ft.
Dehumidification Capacity	71 pints per day
Fan Speeds	3
Weight	80 lbs
Power Supply	115 V / 60 Hz
Refrigerant	R-32
Filter	Washable pre-filter and activated carbon filter
Thermostat Range	61°F - 89°F
Operating Temperature	61°F - 89°F
Window Kit Included	Yes
Exhaust Hose Length	60 inches
