WHYNTER 11,000 BTU DUAL HOSE PORTABLE AIR CONDITIONER

co

Instruction Manual

MODEL# : ARC-110WD

Congratulations on your new WHYNTER product. To ensure proper operation, please read this Instruction

Manual carefully before using this product. Keep this manual in a safe place for future reference.

Table of Contents

Questions and Answers:

P
Phillip McneilJul 26, 2025
Why the air coming out of Whynter ARC-110WD Air Conditioner is not very cold?
- W
  washingtonpeterJul 26, 2025
  If the air coming out of your Whynter Air Conditioner isn't very cold or the airflow is weak, the filters might be dirty, so clean them. Also, check for obstructions in the air intake or exhaust; ensure at least 20" of clearance from the air intake. Keep the exhaust hose as short as possible. Make sure the unit is set to cooling mode and try setting it to a higher fan speed.
J
jennifer95Jul 31, 2025
What to do if Whynter Air Conditioner is very noisy?
- A
  Ana BruceJul 31, 2025
  If your Whynter Air Conditioner is making a lot of noise, ensure it's placed on a hard, level, and stable surface. If the surface is uneven, move the unit to a location with a level and hard floor. Also, ensure the wall outlet supports the air conditioner's power consumption and avoid using an extension cord, as low power voltage can cause noise.
R
Robert ValdezAug 4, 2025
What to do if Whynter ARC-110WD leaks water?
- D
  Dalton FernandezAug 5, 2025
  If your Whynter Air Conditioner is leaking water, make sure the unit is leveled. If the water tank is full, drain water from the drain plugs at the back of the air conditioner.
A
Amber LittleAug 10, 2025
Why Whynter ARC-110WD Air Conditioner does not turn on?
- B
  Brent BuchananAug 10, 2025
  Your Whynter Air Conditioner might not be turning on due to several reasons: a power failure or outage, a tripped switch, fuse, or breaker, low power supply voltage, a damaged power cord, a tripped L.C.D.I. power plug, or a full internal water reservoir. To resolve this: restore the power supply, flip the switch/change the fuse/turn the breaker back on, move other appliances to another circuit if too many are drawing power, move the unit to another circuit with the correct voltage, press the Reset button on the L.C.D.I. power plug, or drain water from the air conditioner. If the power cord is damaged, call for service; only authorized personnel should replace it.
J
John CraneAug 15, 2025
Why Whynter Air Conditioner unit turns on but the compressor does not turn on?
- C
  Chelsea JacksonAug 15, 2025
  If your Whynter Air Conditioner turns on, but the compressor doesn't, it could be due to the room temperature being outside the unit's operational range (64°F to 95°F). Also, make sure the COOL light is displayed by pressing the MODE button. Note that the compressor needs 3 minutes to start after selecting the Cooling mode. Try setting the air conditioner to a lower temperature, ideally at least 5°F below the ambient temperature. If the water tank is full, manually drain the water or allow the unit to exhaust it in fan-only mode, then cooling will resume.
C
Christopher CastroAug 20, 2025
What to do if Whynter ARC-110WD Air Conditioner has worked for a long time, but the room is not cold enough?
- S
  Scott CampbellAug 20, 2025
  If your Whynter Air Conditioner has been running but the room isn't cold enough, close all windows and doors. Close curtains or blinds to minimize direct sunlight. You may need additional cooling or another air conditioner.

Whynter ARC-110WD Specifications

General

Model Number	ARC-110WD
Type	Portable Air Conditioner
Cooling Area	350 sq. ft.
Dehumidifying Capacity	71 Pints per day
Voltage	115V / 60Hz
Noise Level	52 dB
Refrigerant	R-410A
Fan Speeds	3
Timer	24-hour
Operating Temperature	61°F - 89°F
Cooling Capacity	11, 000 BTU

Summary

SAFETY PRECAUTIONS

IDENTIFICATION OF ACCESSORIES

IDENTIFICATION OF PARTS

INSTALLATION INSTRUCTIONS

Exhaust hose Installation

Instructions for connecting and positioning the exhaust hose for optimal performance.

Window kit Installation

Steps for installing the window kit to vent hot air effectively.

AIR FILTERS INSTALLATION

OPERATION INSTRUCTIONS

REMOTE CONTROL PANEL

Overview of the remote control's display, buttons, and functions.

FRONT PANEL

Description of the physical front panel controls and indicators on the unit.

COOLING MODE

How to use the cooling function, set temperature, and fan speed.

DEHUMIDIFYING MODE

Details on using the dehumidifying function and water drainage.

FAN ONLY MODE

Instructions for operating the unit in fan-only mode, including exhaust hose removal.

AUTOMATIC MODE

How the unit automatically selects cooling or fan operation based on ambient temperature.

WATER DRAINAGE

Procedures for manual and continuous water drainage from the unit.

CARE AND MAINTENANCE

CLEANING THE PRE-FILTER

Instructions for cleaning the washable pre-filter to ensure efficient operation.

CLEANING THE AIR CONDITIONER

How to clean the exterior of the air conditioner using appropriate methods.

END OF SEASON STORAGE

Steps for storing the air conditioner at the end of the cooling season.

TECHNICAL DATA

TROUBLESHOOTING

WARRANTY INFORMATION
