WHYNTER ECO-FRIENDLY 14,000 BTU PORTABLE AIR CONDITIONER
co
Instruction Manual
MODEL# : ARC-14S
Congratulations on your new WHYNTER product. To ensure proper operation, please read this Instruction
Manual carefully before using this product. Keep this manual in a safe place for future reference.

Table of Contents

Other manuals for Whynter ARC-14S

Preview: User Manual
User Manual12 pages

Questions and Answers

  • L
    Laura JonesAug 17, 2025
    Why my Whynter ARC-14S Air Conditioner turns on but is not cooling?
    • P
      Paul WigginsAug 17, 2025
      If your Whynter Air Conditioner turns on, but the compressor doesn't, and the fan runs without cooling, it might be because the room temperature is outside the unit's operational range (64°F to 95°F), the Cooling mode isn't activated, the compressor is within its 3-minute time delay, the set temperature is too high, or the internal water reservoir is full. To fix this, ensure the room temperature is within the specified range. Press the MODE button until the COOL light appears. Allow 3 minutes for the compressor to start after selecting Cooling mode. Lower the set temperature, ideally at least 5°F below the ambient temperature. Drain the water manually or by running the unit in fan-only mode to allow it to exhaust the water, after that cooling should resume.
  • B
    Brian BennettAug 19, 2025
    Why Whynter ARC-14S Air Conditioner is not cooling room enough?
    • O
      Olivia KennedyAug 20, 2025
      If your Whynter Air Conditioner has been running for a while but the room isn't cold enough, it could be due to open windows or doors, too many people in the room, direct sunlight, a kitchen or heat-producing appliances, a server in the room, or the room being too large. To address this, close all windows and doors. You might need additional cooling or another air conditioner. Close curtains or blinds to minimize direct sunlight. Additional cooling or another unit may be necessary.
  • A
    Adam LandryAug 22, 2025
    Why is my Whynter ARC-14S running but not cooling?
    • E
      Emily EvansAug 22, 2025
      If your Whynter Air Conditioner turns on, but the compressor doesn't, and the fan is running but not cooling, it might be because the room temperature is outside the unit's operational range of 64°F to 95°F. Ensure the Cooling mode is activated by pressing the MODE button until the COOL light appears. Also, the compressor might be on a time delay, so allow it 3 minutes to start after selecting Cooling mode. Check that the set temperature isn't too high; it's best to set it at least 5°F lower than the room temperature. Lastly, if the internal water reservoir is full, manually drain it or allow the unit to exhaust the water by running it in fan-only mode.
  • N
    Nicholas WardAug 25, 2025
    How to improve cold airflow from my Whynter ARC-14S Air Conditioner?
    • A
      Andrew CookAug 26, 2025
      If the air coming out of your Whynter Air Conditioner isn't very cold, or the airflow is weak, it could be due to dirty or obstructed filters, blocked air intake or exhaust, the unit being set in DRY or FAN mode, or the fan speed being set too low. To solve this, clean the air filters and ensure there's at least 20" of clearance from the air intake. Shorten the exhaust hose as much as possible. Switch the unit to cooling mode and increase the fan speed.
  • M
    Molly NielsenAug 28, 2025
    How to fix weak airflow from my Whynter Air Conditioner?
    • S
      Spencer LeeAug 28, 2025
      If the air coming out of your Whynter Air Conditioner isn't very cold or the airflow is weak, start by cleaning the air filters, as they may be dirty or obstructed. Ensure that the air intake and exhaust are not blocked, maintaining at least 20" of clearance from the air intake and keeping the exhaust hose as short as possible. Verify that the unit is set to cooling mode, not DRY or FAN mode. Also, check the fan speed setting and increase it if it's set too low.
  • R
    Robert CarterAug 30, 2025
    What to do if my Whynter ARC-14S Air Conditioner does not turn on?
    • S
      Steven BellAug 30, 2025
      If your Whynter Air Conditioner doesn't turn on, it could be due to a power failure or outage, a tripped switch, fuse, or breaker, low power supply voltage, a damaged power cord, a tripped L.C.D.I. power plug, or a full internal water reservoir. To resolve this, restore the power supply, flip the switch, change the fuse, or turn the breaker back on. Consider moving other appliances to another circuit to avoid overloading one circuit. Use a circuit with the correct voltage. If the power cord is damaged, call for service (only authorized personnel should replace it). Press the Reset button on the L.C.D.I. power plug. Finally, drain water from the air conditioner.
  • B
    berrymichealSep 2, 2025
    Why is my Whynter Air Conditioner so noisy?
    • J
      Jacob TorresSep 2, 2025
      If your Whynter Air Conditioner is very noisy, it might not be level or the surface underneath is uneven, or there might be low power voltage. Ensure the unit is on a hard, level, and stable surface. Move it to a location with a level and hard floor. Ensure the wall outlet supports the air conditioner's power consumption and avoid using an extension cord.
  • L
    ljohnsonSep 5, 2025
    What to do if my Whynter ARC-14S is leaking water?
    • M
      Matthew HolmesSep 5, 2025
      If your Whynter Air Conditioner leaks water, it could be because the unit is tilted or not leveled, or the water tank is full. To fix this, ensure the unit is leveled and drain water from the drain plug at the back of the air conditioner.
  • W
    Wesley MooreSep 7, 2025
    Why I can't change fan speed on my Whynter Air Conditioner?
    • I
      Ian RossSep 7, 2025
      The fan speed difference is not very noticeable when the compressor is on. Try setting the Whynter Air Conditioner to Fan only mode, you should be able to hear the difference between high and low fan speed settings.
  • T
    Thomas BryanSep 12, 2025
    Why is my Whynter Air Conditioner leaking water?
    • M
      Madison FaulknerSep 12, 2025
      If your Whynter Air Conditioner is leaking water, it could be due to the unit being tilted or not leveled, so make sure the unit is leveled. Another reason could be that the water tank is full. If that's the case, drain water from the drain plug at the back of the air conditioner.

Summary

SAFETY PRECAUTIONS

General Safety Guidelines

Essential safety guidelines and warnings to prevent injury and damage.

OPERATING YOUR AIR CONDITIONER

Control Panel Functions

INSTALLATION INSTRUCTIONS

Location and Exhaust Hose Installation

Guidance on unit placement and connecting the exhaust hose for proper ventilation.

Window kit Installation

Window Kit Setup

Instructions for installing the window kit for exhaust hose setup.

AIR FILTERS INSTALLATION

Filter Installation and Maintenance

OPERATION INSTRUCTIONS

Initial Setup and Modes

Auto Restart and Water Drainage

REMOTE CONTROL

Battery Installation and Functions

CARE AND MAINTENANCE

TROUBLESHOOTING

Unit Not Turning On or Cooling

Solutions for common issues like the unit not powering on or not cooling.

Weak Airflow or Cooling

Advice for improving cooling performance and addressing weak airflow.

Insufficient Cooling and Noise Issues

Troubleshooting Cooling and Noise

Troubleshooting steps for insufficient cooling and excessive noise.

Water Leaks and Fan Speed

WARRANTY INFORMATION

Whynter ARC-14S Specifications

General IconGeneral
Cooling Capacity14, 000 BTU
Coverage AreaUp to 500 sq. ft.
Dehumidification Capacity71 pints per day
Fan Speeds3
Weight80 lbs
Power Supply115 V / 60 Hz
RefrigerantR-32
FilterWashable pre-filter and activated carbon filter
Thermostat Range61°F - 89°F
Operating Temperature61°F - 89°F
Window Kit IncludedYes
Exhaust Hose Length60 inches
