Whynter ARC-142BX User Manual (English)

Questions and Answers:

W
wandahillAug 2, 2025
Why Whynter ARC-142BX turns on but is not cooling?
- R
  Roy RuizAug 3, 2025
  If your Whynter Air Conditioner turns on, but the compressor doesn't, here's what to check: First, ensure the room temperature is within the unit's operational range of 63°F to 90°F. Second, verify that the Cooling mode is activated by pressing the MODE button until the COOL light appears. Third, allow the compressor 3 minutes to turn on after selecting Cooling mode, as there is a time delay. Fourth, lower the set temperature; it's best to set it at least 5°F below the ambient temperature. Fifth, if ‘P1’ is displayed, either manually drain the water by removing the drain plug or run the unit in fan-only mode to exhaust the water. After that, cooling should resume. Lastly, a loose internal connection could be the issue, so contact Whynter for service.
D
Dr. Darlene BrightAug 7, 2025
What to do if Whynter ARC-142BX Air Conditioner is not blowing cold air?
- T
  Thomas EdwardsAug 7, 2025
  If the air from your Whynter Air Conditioner isn't very cold or the airflow is weak, start by cleaning the air filters if they are dirty or obstructed. Then, ensure that there is at least 20" of clearance from the air intake and keep the exhaust hose as short as possible to avoid obstructions. Also, check that the unit is set to cooling mode, not DRY or FAN mode. Finally, increase the fan speed if it's currently set to low.
K
Kaitlyn LambertAug 12, 2025
Why Whynter ARC-142BX is not cooling enough?
- C
  crussellAug 12, 2025
  If your Whynter Air Conditioner isn't cooling the room adequately after running for a while, consider these factors: Check if windows or doors are open and close them. If there are too many people, a server, or heat-producing appliances in the room, or if the room is too large, you may need additional cooling or another air conditioner. Also, minimize direct sunlight by closing curtains or blinds.
J
Jessica WoodAug 15, 2025
How to make Whynter ARC-142BX quieter?
- M
  Mr. Brandon AndersonAug 15, 2025
  If your Whynter Air Conditioner is very noisy, first ensure it's on a hard, level, and stable surface. If the surface underneath is uneven, move it to a location with a level and hard floor. Also, make sure the wall outlet supports the air conditioner's power consumption and avoid using an extension cord, as low power voltage can contribute to noise.
M
Mark MarksAug 20, 2025
What to do if Whynter ARC-142BX Air Conditioner is leaking water?
- L
  lisahernandezAug 21, 2025
  If your Whynter Air Conditioner is leaking water, ensure that the unit is leveled. If the water tank is full, drain the water from the drain plug at the back of the unit.
A
Andrew BallAug 25, 2025
Why can't I change the fan speed on my Whynter ARC-142BX Air Conditioner?
- I
  Ian KennedyAug 25, 2025
  If you can't change the fan speed on your Whynter Air Conditioner, note that the fan speed difference might not be very noticeable when the compressor is running. Try setting the unit to Fan only mode to better hear the difference between high and low fan speed settings.

Whynter ARC-142BX Specifications

General

Model Number	ARC-142BX
Type	Portable Air Conditioner
Cooling Capacity	14, 000 BTU
Coverage Area	500 sq. ft.
Refrigerant	R-410A
Voltage	115V / 60Hz
Fan Speeds	3
Thermostat Range	61°F - 89°F
Noise Level	52 dB
Net Weight	80 lbs
Dehumidifying Capacity	101 Pints per day
Power Consumption	1350 W
Exhaust Hose Length	60 inches
Features	Remote control, 24-hour timer
Operating Modes	Air Conditioner, Fan, Dehumidifier
Warranty	1-year limited warranty

Summary

Disposal and Recycling Information

Safety Precautions

General Safety Dangers

Critical safety warnings regarding electrical shock, fire hazards, and improper usage.

Operational Warnings

Important warnings for safe operation, including placement, ventilation, and environmental conditions.

Operating Conditions and LCDI Plug

Operating Modes and Temperatures

Specifies optimal room temperatures for COOL and DRY modes.

LCDI Plug Functionality

Instructions for testing and ensuring the Leakage-Current Detection and Interruption plug works.

Accessory Identification

Parts Identification

Front Panel Parts

Identifies components on the front of the air conditioner unit.

Rear Panel Parts

Identifies components located on the rear of the air conditioner unit.

Operating the Air Conditioner

Control Panel Overview

Details the functions of each button and the LED display on the control panel.

Installation Instructions

Location Requirements

Guidance on proper placement for efficient air-conditioning and ventilation.

Exhaust Hose Installation

Steps for connecting and extending the exhaust hose for hot air removal.

Window Kit Installation

Standard Window Setup

Instructions for fitting the window kit into standard vertical and horizontal windows.

Double-Hung Window Kit Installation

Sealing Double-Hung Windows

Steps for applying foam seals and securing the window kit in double-hung windows.

Sliding Door/Window Kit Installation

Sealing Sliding Doors/Windows

Steps for sealing and securing the window kit in sliding doors or windows.

Air Filter Installation and Maintenance

Filter Types and Function

Details on the washable pre-filter and activated carbon filter.

Filter Removal Procedure

Instructions on how to remove and replace the air filter frame and carbon filter.

Operation Instructions

Basic Operation

Steps for preparing the unit and switching it on/off.

Cooling Mode

How to use the air conditioner for cooling and dehumidifying.

Dry Mode

Instructions for dehumidifying the room without significant cooling.

Automatic and Fan Modes

Using AUTO mode for automatic selection and FAN mode for air circulation.

Advanced Operation Features

Timer Functions

Setting delayed switch ON and OFF timers for the air conditioner.

Sleep Mode and Auto Restart

Using sleep mode for energy saving and auto-restart after power loss.

Air Flow Control and Noise

Adjusting louvers and understanding normal operating sounds.

Water Drainage

Manual Drainage Procedure

How to drain accumulated water from the unit manually.

Continuous Drainage Setup

Instructions for setting up continuous water drainage using a hose.

Remote Control Operation

Remote Control Usage

How to operate the air conditioner using the remote control and signal transmission.

Battery Installation

Guidance on installing and replacing batteries in the remote control.

Remote Control Buttons

Detailed explanation of each button's function on the remote control.

Care and Maintenance

Cleaning Air Filters

Instructions for cleaning the upper and lower air filters regularly.

Cleaning the Air Conditioner

Methods for cleaning the exterior of the air conditioner unit.

End of Season Storage

Steps for preparing and storing the unit at the end of the cooling season.

Technical Data and Specifications

Troubleshooting Common Issues

Unit Not Turning On

Diagnosing and resolving issues when the air conditioner does not power on.

Compressor Not Engaging

Troubleshooting why the fan runs but the compressor does not cool.

Weak Airflow or Cooling

Resolving problems with insufficient cold air or low airflow volume.

Advanced Troubleshooting

Room Not Cooling Enough

Addressing scenarios where the room temperature is not decreasing sufficiently.

Unit Noise Issues

Identifying and resolving causes for the unit operating noisily.

Water Leaks and Fan Speed

Troubleshooting water leaks and issues with fan speed adjustments.

Warranty Information

Limited Warranty Coverage

Details of the one-year limited warranty and three-year compressor warranty.

Warranty Exclusions

Items and conditions not covered by the product warranty.

Contacting Support

Information on how to obtain service or information from Whynter LLC.
