7|P a g e
6
IDENTIFICATION
OF PARTS
Front
1. Control Panel
2. Front Air Vent / Louvers
3. Caster (four)
4. Handle (both sides)
Rear
6. Upper air filter
7. Air outlet (hot air exhaust)
8. Power cord outlet
9. Upper air intake
10. Upper drain port
11. Lower air intake (Compressor)
12. Lower air filter
13. Lower drain port
