05 HMI BAR MOUNT
5.4 Charge Level & Errors
Error Code Information Table:
Code Condition User Handling Retailer Handling
1 Hardware break - Please turn on and off for a few times
- Please contact your nearest service shop
- Please turn on and off for a few times
- Please return the controller to Whyte/Kynamic
Service Center
2 Battery current over protection setting Please contact your nearest service shop Please check battery cable and connector to see if
there is an abnormal and short-circuit condition
3 Phase current over protection setting Please contact your nearest service shop Please check motor cable and connector to see if
there is an abnormal and short-circuit condition
4 Battery voltage over protection setting Please contact your nearest service shop Please check battery voltage
5 Motor hall sensor signal error or lost Please contact your nearest service shop - Please check motor cable and connector to see if
connection is ne or short-circuit condition
- Please check hall sensor in the motor
6 Motor blocked - Please check motor and wheel if it is
blocked
- Please check motor cable connection is ne
- Please check motor and wheel if it is blocked
- Please check if motor cable connection is ne
- Please check if torque sensor connection is ne
7 Torque sensor signal over protection setting Please contact your nearest service shop - Please check if torque sensor connection is ne
- Please check torque sensor status
8 Torque sensor signal under protection setting Please contact your nearest service shop - Please check if torque sensor connection is ne
- Please check torque sensor status
9 Torque sensor signal under protection setting Please contact your nearest service shop - Please check if throttle connection is ne
- Please check throttle status
10 Throttle signal under protection setting Please contact your nearest service shop - Please check if throttle connection is ne
- Please check throttle status
