27
06 HMI INTEGRATED
6.1 On/Off
CAUTION - Before your ride:
• Regardless of your experience level, you should read the User
Manual carefully and carry out all important safety checks.
• The eBike system can only operate when the battery is sufciently
charged.
Product Features
All illustrations of bike parts except for the drive unit, on-board computer
(including operating unit), speed sensor and the corresponding holders are a
schematic representation and may differ on your eBike. The numbering of the
components shown refers to the illustrations on the graphics to the right.
Operation Requirements
Your eBike system can only be activated when a sufciently charged battery is
inserted (see battery operating instructions).
Power On/Off
Press and hold the Power/Mode button (1) to turn on/off.
Start up logo will be displayed for 3 seconds after initiating power to the
controller. Then the home screen will be displayed.
