Starting and operating Chapter 5
18.07.2013 Working Instructions WIDOS ESI 4000 Page 20 of 37
Press <Start> - button
In case traceability has been confirmed with "yes", (chapter: 5.12) the display indicates:
Display:
2nd line:
Please read
trac.Code (fitting)
Either: Read in traceability 1 of the fitting via the bar code reading pen
Or: Keep button <+> pressed for 4 s, then manually enter the socket bar code
via the buttons <+ / - / Start>
Display:
2nd line:
Traceability 1:
FR PE100 50 4.5
After a few seconds the display changes to
Display:
2nd line:
Please read addit.
trac.Code 2nd pipe
Either: Read in traceability 2 of lefthand pipe with barcode reader
Or: Keep button <+> pressed for 4 s, then manually enter the 2nd socket bar
code via the buttons <+ / - / Start>
Or: skip with <Start>
Display:
2nd line:
Traceability 2:
FR PE100 50 4.5
After a few seconds the display changes to
Display:
2nd line:
Please read addit.
trac. Code 3rd pipe
Either: Read in traceability 3 of righthand pipe with barcode reader
Or: Keep button <+> pressed for 4 s, then manually enter the 3rd socket bar
code via the buttons <+ / - / Start>
Or: skip with <Start>
Display:
2nd line:
Traceability 3:
FR PE100 50 4.5
After a few seconds the display changes to
