WiiM Ultra User Manual Version 1.2 12/30/2024
14
USB OUT: Outputs high quality audio to an external
DAC or other audio device with a USB audio input.
Note: Use a USB hub to connect both USB IN and
USB OUT simultaneously.
LINE OUT
Outputs analog audio, ideal for connecting to an
external amplifier, powered speakers, or audio
receiver.
SUB OUT
Connects to a powered subwoofer and outputs a
signal at 2.0 Vrms.
COAX OUT
Outputs digital audio up to 192 kHz/24-bit with low
jitter.
12V TRIGGER OUT
3.5 mm port for cable connection to your amplifier
for automated power control.
Load-carrying capacity: DC 12V/200mA
Note: Consult your amplifier's user guide for
specifics on utilizing its 12V trigger input.
OPTICAL OUT
Outputs high-quality digital audio up to 192 kHz/24-
bit with low jitter.
LAN
10/100Mbps Ethernet port
Power Input
100-240V AC input, 50/60 Hz, 0.5A Max
