WiiM Ultra User Manual Version 1.2 12/30/2024
30
Scenario 4: Phono In Audio Source Input (Turntable)
The Phono In port on the WiiM Ultra is specifically designed to connect to a turntable
without a built-in preamp.
Cable Requirement:
⚫ Use a turntable RCA cable.
⚫ If the turntable has a ground wire, the provided PHONO ground adapter is needed.
Cable Connection Steps:
1. Connect the red and white RCA connectors on one end of the cable to the
corresponding Phono In ports on the WiiM Ultra.
2. Connect the other end of the cable to the corresponding output port on the
turntable.
3. If your turntable has a ground wire, attach it to the provided Phono ground
adapter and plug the adapter into the Ground port on the WiiM Ultra.
