6. Commissioning, operation
Resistance thermometers with cable connection or male connector
Lemosa connector,
(male) on cable
Binder male connector,
tted to cable
1 x Pt100
2-wire
1 x Pt100
3-wire
1 x Pt100
4-wire
2 x Pt100
2-wire
red
white
white
red
2 x Pt100
3-wire
red
white
white
red
red
yellow
white
yellow
black
white
red
black
black
red
red
Cable
