SECTION 1 - OPTIMUM OVAL ABOVE GROUND POOL
INSTALL LINER
STEP
14.1 Check sand in pool is level.
Remove liner from carton and unfold.
Loosely refold and unfold in the pool from the
outside.
Snap liner bead into receiver track around entire
pool.
Remove as many wrinkles as possible by pulling or
using a soft broom.
(A shop vacuum can be used to remove wrinkles by
attaching vac hose to skimmer outlet and seal with
duct tape. Remove vac after 6” water lled).
15.1 Fill pool.
When water level reaches 2”-3” from return valve
install faceplates. When faceplates installed,
complete lling pool.
16.1 Locate screw holes for each opening in pool wall.
Carefully pierce liner with a nail or awl.
Attach skimmer and return faceplates using 1”
screws and tighten.
14.1
16.1
15
FILL WITH WATER
STEP
16
INSTALL FACE PLATE
STEP
