Wilbar Optimum OVAL - Parts Quantities by Pool Size

9
SECTION 1 - OPTIMUM OVAL ABOVE GROUND POOL
PART PART NO. 16 X 24 16 X 28 16 X 32 18 X 30 18 X 34
1 Panels
16FT Radius Curved Panel 74-5/8 77055 7 7
16FT Radius Curved Panel-R 74-5/8 77071 1 1
18FT Radius Curved Panel 83-3/4 77056 7
18FT Radius Curved Panel-R 83-3/4 77072 1
2 Bottom Plate 77004 6 6 6
3 Top Rail, Curved
Top Rail (77 1/16"long)
77006 8 8
Top Rail (86 9/16" long) 77007 8
4 Cap Screws, 1/2" long 99-0138 50 60 60
5 Top Rail Clips 77005 10 12 12
6 Splines, Long 77002 24 32 32
7 Bolts, Long, hex Head 2 1/2" 99-0137 12 12 12
8 Nuts 99-0134 28 40 40
9 Skimmer, Foam Insert 77070 1 1 1
10 White Skimmer Plate 77063 1 1 1
11 Gray Skimmer Plate 77061 1 1 1
12 White Return Plate 77064 2 2 2
PARTS PER POOL SIZE
