SECTION 2 - OPTIMUM OVAL SEMI IN GROUND AND IN GROUND POOL
CURVED PANEL INSTALLATION
STEP
6.1 Put one Bottom Plate on each Patio Block.
Place wall panel with Skimmer cutout close to site
of electrical outlet. Place skimmer panel and the
next panel symmetrically over the bottom plate.
6.2 Slide two splines into compression seams to lock
panels together (do not force) – splines and seams
must be free of sand and dirt. If the spline sticks,
apply cooking oil (do not use petroleum lubricants
like WD-40).
Repeat this with all the remaining panels.
Drill 7/16 holes through Pool Panels at Bottom Plate
hole locations and secure with 2 ½” bolts and nuts.
Note – Before nal panels are attached, bring in
sand for oor and cove (see above for quantity).
6.1
6.2
