Wilden P200 - Table of Contents

WIL-11070-E-15 Wilden
®
2
Contents
Section 1: Precautions - Read First! 4
Section 2: Wilden Pump Designation System 5
Section 3: How It Works—Pump & Air Distribution System 6
Section 4: Dimensional Drawings 7
P200 Plastic - Polyurethan e 7
P200 Plastic - PVDF 7
P200 Plastic - Polyurethan e , Center Ported 8
P200 Pla s ti c - PVDF, Cen t er Ported 8
Section 5: Performance 9
P200 P la s ti c Rubber-Fit te d 9
P200 P la s ti c T PE-Fitted 9
P200 P la s ti c Reduced- St r oke PTFE - F i tted. 10
P200 Pla s ti c Full-Stroke PTFE-Fitted . 10
Suction- L i ft Curves 11
Section 6: Suggested Installation, Operation, 12
Maintenance and Troubleshooting
Section 7: Disassembly / Reassembly 15
Pump Disa ss e m b ly 15
Air Valve / Center Section D isa ss e m b ly 18
Reassembly H i n ts & Tips 20
Section 8: Exploded View and Parts List 21
P200 Pla s ti c . 21
Section 9: Elastomer Options 23
