WIL-10183-E-04 28
P4 Clamped Metal
Item Description Qty. P4/SSPPP/1935/2004/EC
Air Distribution Components
1 Air Valve Assembly, Pro-Flo
1
1 04-2000-20-700
2 O-Ring, End Cap (-225, Ø1.859" x Ø.139") 1 04-2390-52-700
3 End Cap 1 04-2330-20-700
4 Screw, SHC, Air Valve (1/4"-20 x 4 1/2") 4 01-6000-03
5 Nut, Square (1/4"-20) 4 00-6505-03
6 Self Tapping Screw, SHC, Air Valve (#10-16 x 1-3/4") 2 04-6351-03
7 Muffler Plate, Pro-Flo 1 04-3180-20-700
8 Gasket, Muffler Plate, Pro-Flo 1 04-3500-52-700
9 Gasket, Air Valve, Pro-Flo 1 04-2600-52-700
10 Center Block Assembly, Pro-Flo
2
1 04-3110-20
11 Sleeve, Theraded, Pro-Flo Center Block 4 04-7710-08
12 Pilot Sleeve Assembly 1 04-3880-99
13 O-Ring, Pilot Spool Retaining (-009, Ø.208" x Ø.070") 2 04-2650-49-700
14 Seal, Shaft 2 08-3210-55-225
15 Gasket, Center Block Pro-Flo 2 04-3526-56
16
ir Chamber, Pro-Flo 2 04-3651-01
17 Screw, SFCHC (3/8"-16 x 1") 8 71-6250-08
18 Retaining Ring 2 04-3890-03
19 Muffler 3/4" MNPT 1 04-3510-99R
20 Bushing, Reducer, 3/4" MNPT to 1/2" MNPT 1 04-6950-20-700
Wetted Path Components
21 Liquid Chamber 2 04-5000-03P
22 Manifold, Discharge Tri-Clamp 1 04-5020-03-70P
23 Manifold, Footed Inlet Tri-Clamp 1 04-5080-03-70P
24 Large Clamp Band
ssembly 2 04-7330-03-70
25 RHSN Bolt, Large Clamp Band (5/16"-18 x 2-1/2") 4 04-6070-03
26 Wing Nut, Large Clamp Band (5/16"-18) 4 08-6661-10
27 Washer, Brass Flat (Ø.340" x Ø.750" x .063") 4 08-6700-07-70
28 Small Clamp Band Assembly 8 04-7100-03-70
29 RHSN Bolt, Small Clamp Band (1/4"-20 x 2-1/4") 8 01-6070-03
30 Wing Nut, Small Clamp Band (1/4"-20) 8 04-6651-10
31 Washer, Brass Flat (Ø.251" x Ø.620" x .063") 8 04-6700-07-70
Valve Balls/Valve Seats/Valve O-Rings
32 Ball, Valve, Pkg 4 1 *
33 Seat, Valve, Pkg 4 1 *
Seat, Valve, Stainless Steel 4 04-1121-03E
34 O-Ring, Valve Seat (-226, Ø.1.984" x Ø.139"), (Not Shown), Pkg 4 1 04-1200-55E
Full Stroke Rubber/TPE/PTFE Components
35 Shaft 1 04-3800-03-700
36 Stud, Shaft (1/2"-20 x 1-7/8") 2 08-6150-08
37 Piston, Inner 2 04-3700-01-700
38 Diaphragm, Primary, Pkg 2 1 *
39 Diaphragm, Back-Up, Pkg 2 1 *
40 Piston, Outer 2 04-4550-03P
Ultra-Flex Components
35 Shaft 1 04-3830-03-700
36 Stud, Shaft (3/8-16 x 1-1/2") 2 04-6152-08
37 Piston, Inner 2 04-3760-01-700
38 Diaphragm Primary, Pkg 2 1 *
39 Piston, Outer 2 02-4550-03P
Reduce Stroke PTFE Components
35 Shaft 1 04-3820-03-700
36 Stud, Shaft (1/2-20 x 1-7/8") 2 08-6150-08
37 Piston, Inner 2 04-3752-01
38 Diaphragm Primary, Pkg 2 1 *
39 Diaphragm, Back-Up, Pkg 2 1 *
40 Piston, Outer 2 04-4600-03P
Reduce Stroke IPD Components
35 Shaft 1 04-3820-03-700
36 Stud, Shaft (1/2-20 x 1-7/8") 2 08-6150-08
37 Piston, Inner 2 04-3755-01
38 Diaphragm Primary, Pkg 2 1 *
39 Diaphragm, Back-Up, Pkg 2 1 *
40 Piston, Outer 2
Full Stroke IPD Components
35 Shaft 1 04-3800-03-700
36 Stud, Shaft (1/2-20 x 1-7/8") 2 08-6150-08
37 Piston, Inner 2 04-3700-01-700
38 Diaphragm Primary, Pkg 2 1 *
39 Diaphragm, Back-Up, Pkg 2 1 *
40 Piston, Outer 2
LW0084 Rev. C
EXPLODED VIEW AND PARTS LIST
1 Air Valve Assembly includes items 2 and 3.
2 Plastic Center Block Assembly includes item 14, and 20.
All boldface items are primary wear parts.
