Wilden P4 - PERFORMANCE; P4 METAL RUBBER-FITTED; P4 METAL TPE-FITTED

WIL-10183-E-04 8
P4 Clamped Metal
SECTION 5
P4 METAL
RUBBER-FITTED
Ship Weights………….Aluminum 13 kg (29 lb)
Stainless Steel 20 kg (45 lb)
Cast Iron 22 kg (49 lb)
Alloy C 23 kg (51 lb)
Air Inlet……………………..……..19 mm (3/4")
Inlet…...…………………...…….38 mm (1-1/2")
Outlet………………...………….32 mm (1-1/4")
Suction Lift……………………5.8 m Dry (19.0’)
8.0 m Wet (26.0’)
Disp. per Stroke
1
……...…......0.98 L (0.26 gal)
Max. Flow Rate……………..288 lpm (76 gpm)
Max. Size Solids……………….4.8 mm (3/16")
1
Displacement per stroke was calculated at 4.8
bar (70 psig) air inlet pressure against a 2.1 bar
(30 psig) head pressure.
Example: To pump 102 lpm (27 gpm) against a
discharge pressure head of 2.7 bar (40 psig)
requires 4.1 bar (60 psig) and 22 Nm
3
/h (13
scfm) air consumption.
Flow rates indicated on chart were determined by pumping water. For optimum life and performance, pumps
should be specified so that daily operation parameters will fall in the center of the pump's performance curve.
Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.
P4 METAL
TPE-FITTED
Ship Weights………….Aluminum 13 kg (29 lb)
Stainless Steel 20 kg (45 lb)
Cast Iron 22 kg (49 lb)
Alloy C 23 kg (51 lb)
Air Inlet……………………..……..19 mm (3/4")
Inlet…...…………………...…….38 mm (1-1/2")
Outlet………………...………….32 mm (1-1/4")
Suction Lift……………………...5.2 m Dry (17’)
8.8 m Wet (29’)
Disp. per Stroke
1
……...…........1.1 L (0.29 gal)
Max. Flow Rate……………..307 lpm (81 gpm)
Max. Size Solids……………….4.8 mm (3/16")
1
Displacement per stroke was calculated at 4.8
bar (70 psig) air inlet pressure against a 2.1 bar
(30 psig) head pressure.
Example: To pump 114 lpm (30 gpm) against
a discharge pressure head of 2.7 bar (40
psig) requires 4.1 bar (60 psig) and 26 Nm
3
/h
(15 scfm) air consumption.
Flow rates indicated on chart were determined by pumping water. For optimum life and performance, pumps
should be specified so that daily operation parameters will fall in the center of the pump's performance curve.
Caution: Do not exceed 8.6 bar
(
125 psi
g)
air suppl
y
pressure.
DIMENSIONAL DRAWING
PERFORMANCE
