Wilden PS15 - Default Chapter; Table of Contents

WIL-10420-E-10 Wilden
®
2
Contents
Section 1: Precautions - Read First! 4
Section 2: Wilden Pump Designation System 5
Section 3: How It Works 6
Section 4: Dimensional Drawings 7
Section 5: Performance 8
PS15 Rubber- F itted 8
PS15 EZ- I nstal l T PE-F itte d 8
PS15 Full- S t r o ke PTF E -F itted 9
Su ction- Lift Cur v e s 10
Section 6: Suggested Installation, Operation, 11
Maintenance and Troubleshooting
Section 7: Disassembly / Reassembly 14
Pu mp Disa ssembly 14
Ai r Valve / Ce nte r Sect ion Disassemb ly 17
Si ngle- Point Ex h a u st 20
Rea ssemb ly Hints & T ips 20
Section 8: Exploded View and Parts List 22
PS15 Metal 22
PS15 Metal Sa n if lo™ 193 5/200 4/ EC 24
Section 9: Elastomer Options 26
