Exploded View and Parts List
Item
Description
Qty.
XPS15/SSAAA/…/0070E
1935/2004/EC
P/N
XPS15/SSSSS/…/0070E
1935/2004/EC
P/N
XPS15/SSSPP/…/0070E
1935/2004/EC
P/N
Air Distribution Components
1
Air Valve Assembly, Pro-Flo SHIFT 1
1
04-2039-01
04-2039-03
04-2039-20
2
O-Ring, End Cap (-225, Ø1.859" x Ø.139")
2
04-2390-52-700
04-2390-52-700
04-2390-52-700
3
End Cap
2
04-2340-01
04-2340-03
04-2330-20-700
4
Screw, SHC, Air Valve (1/4"-20 x 4-1/2")
4
01-6000-03
Screw, SHC, Air Valve (1/4"-20 x 4-1/2")
6
01-6000-03
01-6000-03
5
Nut, Square (1/4"-20)
6
00-6505-03
6
Muffler Plate, Pro-Flo SHIFT
1
04-3189-01
04-3189-03
04-3189-20
7
Gasket, Muffler Plate, Pro-Flo SHIFT
1
04-3509-52
04-3509-52
04-3509-52
8
Gasket, Air Valve, Pro-Flo SHIFT
1
04-2639-52
04-2639-52
04-2639-52
9
Center Block Assembly, Pro-Flo SHIFT 2,3
1
15-3129-01
15-3129-03
15-3129-20
10
Sleeve, Threaded, Center Block
4
04-7710-08
11
Pilot Sleeve Assembly
1
15-3884-99
15-3884-99
15-3884-99
12
O-Ring, Pilot Spool Retaining (-009, Ø.208" x Ø.070")
2
04-2650-49-700
04-2650-49-700
04-2650-49-700
13
Seal, Shaft
2
15-3210-55-225
15-3210-55-225
15-3210-55-225
14
Bushing, Shaft
2
15-3306-13
15-3306-13
15-3306-13
15
Gasket, Center Block Pro-Flo SHIFT
2
04-3529-56
04-3529-56
04-3529-56
16
O-Ring, (-210, Ø.734" x Ø.139")
2
04-3209-49
04-3209-49
04-3209-49
17
Air Control Spool
1
15-3859-03
15-3859-03
15-3859-03
18
O-Ring, Air Control Spool Retaining (-114, Ø.612" x Ø.103")
2
04-3879-50
04-3879-50
04-3879-50
19
Air Chamber, Pro-Flo V™
2
15-3660-01
15-3660-03
15-3660-03
20
Screw, HHC (3/8"-16 x 1-1/8")
8
15-6130-08
Screw, HHC (3/8"-16 x 1")
8
08-6130-03
08-6130-03
21
Washer, Flat (Ø.406" x Ø.812" x .065")
8
15-6740-08-50
04-6740-03
04-6740-03
22
Retaining Ring
2
04-3890-03
04-3890-03
04-3890-03
23
Grounding Screw, (10-32 x 1/2") Self Tapping
1
04-6345-08
04-6345-08
N/A
24
Bushing, Reducer 1-1/2" MNPT to 1" FNPT
1
04-6959-17
25
Muffler 1" MNPT
1
15-3514-99
26
Muffler 1-1/2" MNPT
1
04-3518-99R
04-3513-99
27
Muffler 1/4" MNPT
1
04-3240-07
04-3240-07
04-3240-07
Wetted Path Components
28
Liquid Chamber
2
15-5000-03P
15-5000-03P
15-5000-03P
29
Manifold, Discharge Tri-Clamp
1
15-5020-03-70P
15-5020-03-70P
15-5020-03-70P
30
Manifold, Footed Inlet Tri-clamp
1
15-5080-03-70P
15-5080-03-70P
15-5080-03-70P
31
Large Clamp Band Assembly
2
15-7300-03-70
15-7300-03-70
15-7300-03-70
32
Screw, HHC Large (1/2"-13 x 3-1/2")
4
15-6120-03
15-6120-03
15-6120-03
33
Wing Nut, Large Clamp Band (1/2"-13)
4
15-6671-10
15-6671-10
15-6671-10
34
Washer, Brass Flat (Ø.516" x Ø.875" x .063")
4
15-6720-07-70
15-6720-07-70
15-6720-07-70
35
Small Clamp Band Assembly
4
15-7100-03-70
15-7100-03-70
15-7100-03-70
36
RHSN Bolt, Small Clamp Band (3/8"-16 x 2")
8
15-6050-03
15-6050-03
15-6050-03
37
Wing Nut, Small Clamp Band (3/8"-16)
8
08-6671-10
08-6671-10
08-6671-10
38
Washer, Brass Flat (Ø.392" x Ø.875" x .063")
8
08-6720-07-70
08-6720-07-70
08-6720-07-70
Valve Balls/Valve Seats/Valve O-Rings
39
Ball, Valve, Pkg 4
1
*
*
*
40
Seat, Valve, Pkg 4
1
*
*
*
Seat, Valve, Stainless Steel
4
15-1121-03E
15-1121-03E
15-1121-03E
41
O-Ring,Valve Seat PTFE-Fitted (-342, Ø3.600"x Ø.210") (Not Shown), Pkg 4
1
15-1200-55E
15-1200-55E
15-1200-55E
Full-Stroke Rubber/TPE/PTFE Components
42
Shaft
1
15-3805-09
15-3805-09
15-3805-09
Shaft, IPD
1
15-3814-09
15-3814-09
15-3814-09
43
Piston, Inner
2
15-3700-01
15-3700-03
15-3700-01
Piston, IPD Inner
2
08-3700-01
08-3700-03
08-3700-01
44
Washer, Inner Piston Backup
2
15-6850-08
15-6850-08
15-6850-08
45
Screw, HHC (3/8"-16 x 1-1/8")
12
15-6130-08
15-6130-08
Screw, HHC (3/8"-16 x 1")
12
08-6130-03
46
Washer (Ø.406" x Ø.812" x .065")
12
15-6740-08-50
04-6740-03
15-6740-08-50
47
Diaphragm, Primary, Pkg 2
1
*
*
*
Diaphragm, IPD Primary, Pkg 2
1
*
*
*
48
Diaphragm, Backup, Pkg 2
1
*
*
*
49
Piston, Outer
2
15-4550-03P
15-4550-03P
15-4550-03P
LW0081 Rev. K
*See elastomer chart - Section 9
2
Metal Center Block Assembly includes items 13, 14 and 16. All boldface items are primary wear parts.
1
Air Valve Assembly includes items 2 and 3
.
.
3
Plastic Center Block Assembly includes items 10, 13, 14 and 16
.
.
