11. Appendix
11.1. Overview of individual symbols
Back(briefpress:onemenulevel;longpress:main
screen)
EASY menu
EXPERT menu
1stmeaning:Servicenotregistered
2ndmeaning:Displayvalue–noentrypossible
Service
Parameters
Information
Fault
Reset error
Alarm settings
Error in power supply (phase error, incorrect rotat-
ingeld,lowvoltage)
Error in motor winding (WSK, PTC, impermeability)
External off
Pump
Pump 1
Pump 2
Pump 3
Pump 4
Pump cycling
Time-dependent pump cycling
Pump test run
Maximum pump running time
Setpoints
Activation and deactivation thresholds
Actual value
Sensor:Signaltype
Sensor:Measurementrange
Pump activation and deactivation delay times
Delay time
Follow-up time
Operating mode
Operating mode of the switchgear
Pump operating mode
Standby
Limit values
Switchgear data
Controllertype;IDnumber;software/rmware
Operating hours
Operating hours of pump 1
Operating hours of pump 2
Operating hours of pump 3
Operating hours of pump 4
Switching cycles
Switching cycles of pump 1
Switching cycles of pump 2
