• High water
• Dry-running protection/water level too low
• 1x input/pump for thermal winding monitoring via
a bimetal or PTC temperature sensor
• 1x input/pump for leakage detection via a mois-
ture probe
• 1x digital input (External OFF) for remote activa-
tion and deactivation of automatic mode
3.5.2. Outputs
• 1x potential-free contact for SSM and SBM
• 1x potential-free contact for the high water alarm
• 1x potential-free contact for starting an external
consumer (e.g. submersible mixer) depending on
standstill times of the connected pumps
• 1xanalogueoutput0-10V,fordisplayofthe
actual level value
3.5.3. Switchgear
Mainsconnection: See rating plate
Max.currentconsumption: See rating plate
Max.switchingcapacity: See rating plate, AC3
Max. fuse protection on
mainsside:
See rating plate
Activationtype: See rating plate
Ambient/operating temper-
ature:
0...40 °C
Storagetemperature: -10...+50 °C
Max.relativehumidity: 50%
Protectionclass: IP54
Controlvoltage: 24 VDC, 230 VAC
Alarm contact switching
capacity:
max. 250 V, 1 A
Housingmaterial:
Steel sheeting, pow-
der-coated exterior
Electricalsafety: Pollution degree II
3.6. Type key
Example: Wilo-Control SC-L 2x12A-M-DOL-WM-Ex
SC
Version:
SC=SmartControlswitchgearforxed-speed
pumps
L
Level-dependent control of pumps
2x
Max. number of pumps that can be connected
12A
Max. rated current in ampere per pump
M
Mainsconnection:
M = alternating current (1~230 V)
T4 = three-phase current (3~ 400 V)
DOL
Pumpactivationtype:
DOL = direct-on-line starting
SD = star-delta activation
WM
Installationtype:
WM = wall-mounted installation
BM=oormodel
OI = outdoor installation with pedestal
Ex
Version for pumps and signal transmitters used
in potentially explosive areas
3.7. Options
• Connection for 3 or 4 pumps
• Customer-specicadjustmentsforspecialappli-
cations
3.8. Scope of delivery
• Switchgear
• Wiring diagram
• TestprotocolinaccordancewithEN60204-1
• Installation and operating instructions
3.9. Accessories
• Float switch for wastewater and sewage free of
faeces
• Float switch for abrasive sewage containing
faeces
• Level sensors
• Printed circuit board for ESM and EBM
• Horn230V,50Hz
• Flashlight230V,50Hz
• Signallamp230V,50Hz
Accessories have to be ordered separately.
4. Transportation and storage
4.1. Delivery
On delivery, check immediately that the ship-
ment is complete and undamaged. If any parts
are damaged or missing, the transport company
orthemanufacturermustbenotiedontheday
of delivery. Claims made after this date cannot be
recognised. Damage to parts must be noted on
the freight documentation.
4.2. Transport
Only the packaging used by the manufacturer or
supplier may be used for transport. This normally
precludes the possibility of damage occurring
during transportation and storage. The packaging
should be stored in a safe place for reuse if the
product is frequently used at different locations.
4.3. Storage
On delivery, switchgears may be placed into tem-
porary storage for up to 1 year until use providing
the details below are observed.
The following should be taken into consideration
forstorage:
• Placethepackagedswitchgearonarmsubsur-
face.
• Our switchgears may be stored at -10 °C to
+50°Catamax.relativehumidityof50%.
The store room must be dry. We recommend a
frost-protected room for storage with a tem-
perature between 10 °C and 25 °C and a relative
humidity of 40% to 50%.
Avoid condensation!
• Seal the threaded cable connections securely to
prevent ingress of moisture.
• Connected power supply cables should be pro-
tected against kinking, damage, and moisture.
