Wilo TS Series User Manual

English
12 WILO SE 09/2008
3 Transport and interim storage
As soon as the product arrives:
• Check the product for damage in transit,
• In the case of transport damage, initiate the nec-
essary procedures with the forwarding agent
within the time stipulated.
CAUTION! Danger of property damage!
Incorrect transport and incorrect intermediate
storage can lead to product damage.
• The pump may only be suspended/carried by the
strap provided for transport purposes. The cable
should never be used for lifting!
• The pump must be protected against moisture,
frost and mechanical damage when transported
and stored.
4Intended use
The Drain-TS series drainage and submersible
waste water pumps are used:
• for the automatic drainage of pits and shafts,
• for keeping dry yard areas and basement rooms
exposed to flooding,
• for lowering surface water,
if the waste water is not able to flow off into the
sewer system through natural fall.
The pumps are suitable for pumping slightly con-
taminated water, rainwater, drainage water and
washing water.
The pumps are usually installed under water (sub-
merged) and can only be permanently or trans-
portably installed vertically. Because of the sheath
current cooling, the pumps can also be operated
unsubmerged.
Submersible pumps with a mains connection cable
of less than 10 metres are (according to EN 60335)
only permitted for use inside buildings, i.e. not for
operating outside.
Pumps that are intended for use in or at garden
ponds or similar places must have a mains con-
necting cable that is not lighter than rubber
sheathed cables reference H07 RN-F (245 IEC 66)
according to EN 60335.
Danger! Mortal danger due to electric shock
The pump many not be used to drain swimming
pools / garden ponds or similar places if anyone
is in the water.
WARNING! Hazardous to health!
Owing to the materials used, the pumps are not
suitable for potable water! Unpurified foul and
waste water represents a health hazard.
CAUTION! Danger of property damage!
Pumping unpermitted substances can lead to
product damage.
The pumps are not suitable for water with
coarse contamination such as sand, fibres or
combustible, caustic fluids or for use in poten-
tially explosive areas.
Correct use of the pump/unit also includes follow-
ing these instructions.
Any use over and beyond these is interpreted as
incorrect use.
5 Product information
5.1 Type key
Example: TS 32/9 A -10M KA,
TSW 32/8 A -10M KA,
TS Series: T = submersible pump
S = wastewater
Wwith turbulator
32 Nominal diameter of pressure port [mm]:
32 = Rp 1¼
/8 Max. delivery head [m] when Q=0m³/h
A A = with float switch
10M KA Length of mains connecting cable [m]: 10
5.2 Technical data
Mains voltage: 1~230 V, ± 10 %
Mains frequency: 50 Hz
Protection class: IP 68
Insulation class: B
Speed: 2900 rpm (50 Hz)
Max. current consumption: See name plate
Power consumption P
1
: See name plate
Max. flow rate: See name plate
Max. delivery head: See name plate
Operating mode: 4000 operating hours a year
Operating mode S3 (optimum): Intermittent duty, 30 %
(3.0 min. operation, 7.0 min. interval).
Recommended switching frequency: 20/h
Max. switching frequency: 50/h
Free ball passage: 10 mm
Nominal diameter of the pressure port: Ø 32 mm (Rp 1¼)
Admissible fluid temperature:
briefly 3 min.:
+3 to 35 °C
90 °C
Max. submersion depth: 10 m
Flat suction up to: 8 mm (TSW: 18 mm)
