Installation and operating instructions Wilo-Stratos PICO 9
English
* The pump is equipped with a power limiting function which provides protection
against overload. This can have an effect on the output depending on operation.
5.3 Scope of delivery
• Complete circulation pump
• including thermal insulation shell
• Wilo-Connector included
• Installation and operating instructions
6 Description and function
6.1 Description of the product
The pump (Fig. 1/1) consists of a hydraulic system, a glandless
pump motor with a permanent magnet rotor, and an electronic
control module with an integrated frequency converter. The
control module includes a red operating knob and an LCD
(Fig. 1/2) for setting all parameters and for displaying the cur-
rent electricity consumption in W, or the effective flow in m³/h
and the cumulative electricity consumption in kWh since com-
missioning.
6.2 Functions
All functions can be set, activated or deactivated using the red
operating knob.
Display of the current power consumption in W.
or
Display of effective flow in m³/h.
Max. operating pressure 10 bar (1000 kPa)
Min. inlet pressure at
+70 °C/+95 °C/+110 °C
0.15 bar/0.3 bar/1.0 bar
(15 kPa/30 kPa/100 kPa)
5.2 Technical data

Wilo Wilo-Stratos PICO 25/1-6 Specifications

General

Max Head	6 m
Voltage	230 V
Protection Class	IP42
Max Operating Pressure	10 bar
Installation Length	180 mm
EEI	≤ 0.20
Type	Circulating Pump
Supply Voltage	1 x 230 V, 50/60 Hz
