E: Pre-cleaning of the pond water.
When the water flows out, it is shortly exposed to UV radiation of the UV lamp. As a result, germs,
bacteria, algae are destroyed. The water circulates when flowing through the filter from inside out-
wards.
F: Water discharge with flow display
The cleaned water flows back into the pond.
G: Hose tails for rinsing water when on cleaning (Für CPF-180-250)
G: Flow indicator (Für CPF-280-500)
G: Hose tails for rinsing water when on cleaning. (CPF-2500-5000-10000-15000-20000-30000)
H: The function-switch changes between "filtration" and "clean filter"
I: Flow indicator (Für CPF-180-250)
When the dirty on the sponge is too much, the turbidimeter will be changed from green color to
yellow color to warn you to clean the sponge.
I: Handle with function (CPF-2500-5000-10000-15000-20000-30000)
J: Clean the filter sponge with handle function. (For CPF-2500-5000-10000-15000-20000-30000)
The filter sponge can be cleaned by turning around the cleaning handle. Installation guidelines with
regard to the clear water guarantee, the following installation guidelines must be observed.
The filter system has to remain switched on for 24 hours a day.
The UV-lamp should be changed after 8.000 operating hours so that the device can work effectively
and efficiently. The filter system must be cleaned regularly.
Connecting the pump:
On the filter cover/lid there are three connections equipped with hose tails. The pump is connected to
the first hose tail. Use a hose diameter that is the same with the diameter of the pump outlet. Saw off
the diameter-hose steps that you do not need.
The hose tail in the middle of the filter cover/lid is the outflow to the pump. Connect to the large diameter
of the tail a suitable hose and cut away the rest of the tail diameter. To avoid the loosening of the hoses
please use hose clamps.
Never use the filter with a built-in UVC-unit with a water pressure higher than 0,2 bar! The height differ-
ence between the filter lid and the pressure-free outflow point of the supply line can amount to max. 2
meter. The pressure of the water pumped to the filter cannot exceed 0,5 bar. Use the filter only with
hoses that can withstand at least a pressure of 0,2 bar, the max. pressure of the pump.
Make sure that outflow /discharge in the pond is positioned on a clean place. If the outflow is blocked a
higher pressure may result. Higher pressure can lead to leaking spots in the filter and therefore to a
complete emptying of the pump.
When the filter is used in „filter-modes“, the user should be careful and make sure that all seals are
properly installed in order to avoid the emptying of the pond. The sealing cap functions simultaneously
as safety measure in „Clean“-mode. Make sure that filter always operates in the „filter-mode“ as long as
the pump is running. The filter should be set on „Clean“, if the filter sponges are cleaned. Before you
start the filter, check and make sure that all hoses and seals are correctly fastened. Filter only water and
no other fluids. By frost the filter has to be removed. Do not expose the filter to the direct sun light.
After the filter has been placed on the right place and the pump has been connected the integrated UV-
unit can be switched on.
