The UV-unit:
The Wiltec Filter is delivered with all the equipment you need and an integrated UV-unit. The UV-PL
lamps have ca. 8000 working hours that correspond to a season period of use from March till November.
The UV-lamps can be replaced by loosening the screws from the spherical upper part of the cover lid.
It is recommended to change the UV-lamp with a new one at the beginning of the season. The UV-lamp
clears as the green water and destroys germs. The Wiltec filters have a separate chamber, through
which UVC-rays are not exposed to contact with the filter media. Because of this the micro organisms
in the filter material are not damaged.
Maintenance / Cleaning/Adjustment Possibilities (setting options) For CPF-180-250 only
A = Pump connection
B = Return pond (backflow)
B1 = Setting – filter operation
C = Watering connection
D = Setting - cleaning
E = Switch / cleaning mechanism
Filter operation: bring the rotating switch E into position B1. With the help of a pump, the water is led
to the filter through the connection A, here it is cleaned and via connection B discharged back into the
pond.
Cleaning operation: bring the switch E into position D. This setting enables the cleaning mechanism,
by pressing down the setting switch E. By means of this pressure, the sponges inside the filter are
squeezed. By using this switch setting the dirty water is not led back into the pump but it is discharged
via connection C and it can be used for garden watering.
