The pond filter of the series CPF-2500-5000-10000-15000-20000-30000 have a fast cleaning function
that can be activated with the aid of the hand crank. Instead of the setting switch (press button), de-
scribed above turn the crank handle so long (like by a salad spinner) until the filter sponges have lost
enough dirt.
The filter materials as well as the lamp should be replaced 1 x year to ensure a problem-free
operation of the filter.
When the filter is used for normal operation, "the watering- connection" (C) with the screwed ring +
sealing and the viewing glass (included in the delivery) should be closed to avoid leaking. The pres-
sure filter model of the series CPF-2500-5000-10000-15000-20000-30000 have a stepped hose tail
with integrated ball valve to close the connection.
Before every commissioning of the filter the user should check if sealings and connections are fitted
correctly. Pressure pond filters are exclusively designed for filtering pond water with typical impurities.
Do not expose the filter to the direct sun light over a longer period.
By frost the filter has to be completely emptied, if necessary dug out and stored in a dry, frost-free
place.
After work that requires the removal of the lid, please make sure when attaching the cover lid that the
sealing rings are fitted correctly! Fit the clamp ring around the lid, press on the cover lid and close the
sealing clam.
CPF-180-250
CPF-280-380-500
CPF-2500-5000-10000-15000-20000-30000
