Cassette initialization Device Overview and Operation
3-32 Cash Media Dispenser Version 4 - Service Manual 01750060162 A
Cassette initialization
The initialization of the cassettes is necessary in case of new types of
banknotes or cassettes. With the initialization the system will be informed
about the cassette number, the currency and the denomination of the
banknotes. If necessary, you can enter more parameters.
Please observe the product-specific and bank requirements concerning
change of standard or individual changing of cassettes. Please obtain this
information from the bank’s administration.
Determining the reference value
The determination of the reference value can be performed for a maximum of
40 different unknown banknotes. It is controlled by the product-specific
software.
The reference value determination is required for:
− Initial operation
− Use of new banknote types.
• Activate the product-specific software (see chapter "Basic Operation",
section "Calling the product-specific software" in the operating manual of
the basic device).
From the specified cassette the currency characteristics, the value of the
banknotes and the emission date will be read out. These values are
transmitted to the cassette when it is initialized. There will be as many
banknotes dispensed as necessary to determine the reference value. The
process of determining the reference value will be terminated at the latest if
the reference value cannot be determined within the maximum possible
number of banknotes. In this c
ase, the cass
ette’
s status remains <P>.
After the reference value has been determined, the dispensed number of
banknotes is reported back to the system.
If no ref
erence value has been determined, the status <P> is reported bac
k to
the system. Dispensing is impossible from this cassette in this case.
The dispensed banknotes are located in the stacking position in the clamp.
• Open the safe door (see the operating manual of the basic device).
