The cassettes Device Overview and Operation
3-8 Cash Media Dispenser Version 4 - Service Manual 01750060162 A
The cassettes
Cash-out cassette
8
3
9
10
4
13
5
12
2
11
7
6
14
1
16
15
1
Pull-back handle 10
Inset for setting the banknote
2
Banknote rail
height
3
Slide for low cash sensor 11
Latching button
(optional) 12
Free space for validity
4
Pressure carriage
identification
5
Tamper indicator blue/green 13
Free space for cassette label
6
Sealing device 14
Cassette handle
7
Locking/unlocking lever / lock 15
Dispensing side
8
Box lid 16
Side of cassette handle
9
Refill notes
